LIJADORA MANUAL DE
ÓRBITA ALEATORIA
PONCEUSE À MAIN ORBITALE
À MOUVEMENT ALÉATOIRE
RANDOM
ORBIT PALM
SANDERS
Pad Size ............................................................................ 3" ..................................................6" ........................................6"
Random Orbit Size ........................................................ 3/32" ............................................ 3/32" .................................. 3/16"
Free Speed ......................................................... 12,000 RPM .................................. 12,000 RPM ........................ 12,000 RPM
Horse Power ................................................................ 0.3 HP ........................................... 0.3 HP ................................. 0.3 HP
Spindle Threads ......................................................... 3/8"-24 ........................................ 3/8"-24 ............................... 3/8"-24
Air Consumption ....................................................... 2.4 CFM .........................................2.4 CFM .............................. 2.4 CFM
Inlet Size ................................................................1/4" NPT ....................................... 1/4" NPT .............................1/4" NPT
Recommended Hose Size ........................................ 3/8" I.D.. ........................................ 3/8" I.D. .............................. 3/8" I.D.
Height w/ pad ..............................................................3-1/2" ........................................... 3-5/8" .................................3-5/8"
Weight w/ pad ............................................................ 1.3 lbs. .......................................... 1.9 lbs. ................................ 1.9 lbs.
Sound Pressure Level ..................................................... 81.2 ...............................................81.2 ................................... 81.2
Vibration Level ...................................................... 4.14 m/s 2 ......................................4.14 m/s 2 ............................4.14 m/s 2
WARNING
ALWAYS READ
INSTRUCTIONS
BEFORE USING
POWER TOOLS
ALWAYS WEAR
SAFETY GOGGLES
ALWAYS WEAR
HEARING
PROTECTION
AVOID PROLONGED
EXPOSURE TO
VIBRATION
S P E C I F I C A T I O N S
MT2533
Some dust created by power sanding, sawing, grinding, drilling, and other
construction activities contains chemicals known to cause cancer, birth defects or
other reproductive harm. Some examples of these chemicals are:
• lead from lead-based paints,
• crystalline silica from bricks and cement and other masonry products, and
• arsenic and chromium from chemically-treated lumber.
Your risk from these exposures varies, depending on how often you do this type
of work. To reduce your exposure to these chemicals: work in a well ventilated
area, and work with approved safety equipment, such as those dust masks that are
specially designed to filter out microscopic particles.
MT2533, MT2532, MT2516
MT2532
WARNING
Copyright © Professional Tool Products, 2019
Operating Instructions
Warning Information
Parts Breakdown
MT2516
All rights reserved.

Publicité

loading

Sommaire des Matières pour Matco Tools MT2533

  • Page 1 MT2533, MT2532, MT2516 LIJADORA MANUAL DE Operating Instructions Warning Information ÓRBITA ALEATORIA Parts Breakdown PONCEUSE À MAIN ORBITALE À MOUVEMENT ALÉATOIRE RANDOM ORBIT PALM SANDERS S P E C I F I C A T I O N S MT2533...
  • Page 2 MT2533, MT2532, MT2516 RANDOM ORBITAL PALM SANDERS WARNING FAILURE TO OBSERVE THESE WARNINGS COULD RESULT IN INJURY • Keep body working stance balanced and firm. Do THIS INSTRUCTION MANUAL CONTAINS not overreach when operating the tool. IMPORTANT SAFETY INFORMATION. • Do not point or indulge in any horseplay with this tool.
  • Page 3 MT2532, MT2516, MT2533 RANDOM ORBITAL PALM SANDERS OPERATION VACUUM KIT To install MT25VCK (Vacuum Kit) Select a suitable abrasive disc and make sure that it is fixed securely to the pad. Connect a suitable air supply as recommended 1. Disconnect air supply.
  • Page 4 MT2532, MT2516, MT2533 RANDOM ORBITAL PALM SANDERS AIR SUPPLY TROUBLESHOOTING Other factors outside the tool may cause loss of power or erratic Tools operate on a wide range of air pressures. It is recommended action. Reduced compressor output, excessive drain on the air line,...
  • Page 5 MT2532, MT2516, MT2533 RANDOM ORBITAL PALM SANDERS MT2533 REF. NO. PART NO. DESCRIPTION QTY. REF. NO. PART NO. DESCRIPTION QTY. RS251601B HOUSING RS316018 ROTOR RS246001 SNAP RING (ISTW-13) RS246021 CYLINDER SET RS251602 VALVE STEM SET RS233224 BUSHING RS251603 REGUALTOR SET...
  • Page 6 MT2532, MT2516, MT2533 RANDOM ORBITAL PALM SANDERS MT2532 REF. NO. PART NO. DESCRIPTION QTY. REF. NO. PART NO. DESCRIPTION QTY. RS251601B HOUSING RS316018 ROTOR RS246001 SNAP RING (ISTW-13) RS246021 CYLINDER SET RS251602 VALVE STEM SET RS233224 BUSHING RS251603 REGUALTOR SET...
  • Page 7 MT2532, MT2516, MT2533 RANDOM ORBITAL PALM SANDERS MT2516 REF. NO. PART NO. DESCRIPTION QTY. REF. NO. PART NO. DESCRIPTION QTY. RS251601G HOUSING - GREEN RS316018 ROTOR RS251601B HOUSING - BURGUNDY RS246021 CYLINDER SET RS251601O HOUSING - ORANGE RS233224 BUSHING RS246001...
  • Page 8 MT2532, MT2516, MT2533 LIJADORA MANUAL DE Instrucciones de Operación ÓRBITA ALEATORIA Inforación de Advertencia Revisión de Refacciones PONCEUSE À MAIN ORBITALE À MOUVEMENT ALÉATOIRE RANDOM ORBIT PALM SANDERS E S P E C I F I C A C I O N E S...
  • Page 9 MT2532, MT2516, MT2533 LIJADORA MANUAL DE ÓRBITA ALEATORIA ADVERTENCIA EL INCUMPLIMIENTO DE OBSERVAR ESTAS ADVERTENCIAS PUEDEN RESULTAR EN ALGUNA LESIÓN lesión seria o la muerte. Sea consciente de la manguera ESTE MANUAL DE INSTRUCCIONES CONTIENE INFORMACIÓN IMPORTANTE DE SEGURIDAD. excedente,...
  • Page 10 MT2532, MT2516, MT2533 LIJADORA MANUAL DE ÓRBITA ALEATORIA OPERACIÓN ENSAMBLE DE LA ASPIRADORA Seleccione un disco abrasivo adecuado y asegúrese que esté Para instalar el MT25VCK (Ensamble de la aspiradora) sujetado seguramente a la almohadilla. Conecte un suministro de aire adecuado, según se recomienda en la Figura 1. La entrada de 1.
  • Page 11 MT2532, MT2516, MT2533 LIJADORA MANUAL DE ÓRBITA ALEATORIA ALIMENTACIÓN DE AIRE LUBRICACIÓN Y MANTENIMIENTO Lubrique el motor neumático diariamente con un aceite para Las herramientas de esta categoría operan dentro de un rango herramientas neumáticas de alta calidad. Si no se usa ningún amplio de presión de aire.
  • Page 12 MT2532, MT2516, MT2533 LIJADORA MANUAL DE Instructions de fonctionnement ÓRBITA ALEATORIA Avertissement Pièces PONCEUSE À MAIN ORBITALE À MOUVEMENT ALÉATOIRE RANDOM ORBIT PALM SANDERS S P É C I F I C A T I O N S MT2533 MT2532 MT2516 Diamètre du tampon ............
  • Page 13 Le port de gants réduit les risques de coupures ou de étiquettes du produit sont perdus ou illisibles, contactez brûlures. Matco Tools pour les faire remplacer. Si l'utilisateur- • Rester à l’écart de l’extrémité de l’outil. Ne portez pas de opérateur de l'outil ne maîtrise pas bien l'anglais, les bijoux ni de vêtements amples.
  • Page 14 MT2532, MT2516, MT2533 PONCEUSE À MAIN ORBITALE À MOUVEMENT ALÉATOIRE INSTRUCTIONS DE FONCTIONNEMENT ENSEMBLE D’ASPIRATEUR Pour installer MT25VCK (Ensemble d’aspirateur) Sélectionnez un disque à poncer approprié et assurez-vous qu'il est fixé solidement au patin. Connectez une alimentation en air appropriée tel que recommandé dans la Figure 1. La prise d'air 1.
  • Page 15 MT2532, MT2516, MT2533 PONCEUSE À MAIN ORBITALE À MOUVEMENT ALÉATOIRE ALIMENTATION EN AIR DÉPANNAGE Des facteurs extérieurs à l’outil peuvent causer des baisses Cet outil peut fonctionner à l’intérieur d’une large plage de de puissance ou d’autres problèmes. Un débit réduit du pression d’air.
