DESCRIPTION

INT104 is an interface intended to perform the link between your computers system and
your broadcast or production studio. Using the computer serial, parallel oder USB port, its
allows direct control of external sources (CD/MD players, mixing console, external
remote controls).
Thanks to the dedicated software, the user keeps the full control of all external or
embedded equipm
INT 104 is fitted with 8

USES

Linking the broadcasting software to the mixing desk.
Linking the mixing desk to the players, under software control.
Linking external players through a specific software.

BLOCK DIAGRAM

TO PC
Parallel
port
Sub-D 25 pts
female
ENGLISH
nt, such as players, mixing console and so on.
e
inputs and 8 outputs in rack mount 19".
To PC
USB Port
6
5
To PC
Serial Port
Sub-D 9 pts
female
µc
8
8
8
10
Dry Loop
Output
Sub-D25 pts
male
Remote
Input
Sub-D25 pts
female
Rami - INT 104
