PERCEUESE PNEUMATIQUE POLYVALENTE REVERSIBLE 1/2"

PERFORADORA NEUMATICA DE COMPUESTOS REVERSIBLE 1/2 PO

COMPOSITE

REVERSIBLE

AIR DRILL

WARNING

RATED RPM OF THE

ACCESSORY USED MUST

RPM

EXCEED THE MAXIMUM

TOOL RPM SHOWN

ALWAYS READ

INSTRUCTIONS

BEFORE USING

POWER TOOLS

ALWAYS WEAR

SAFETY GOGGLES

ALWAYS WEAR

HEARING PROTECTION

AVOID PROLONGED

EXPOSURE TO

VIBRATION

Max. Free Speed ............................................................................................. 500 RPM

Spindle Thread Size .........................................................................................1/2" x 20

Air Inlet ........................................................................................................... 1/4" NPT

Min. Air Hose Size .............................................................................................. 3/8" ID

Average Air Consumption ......................................................................................4 CFM

Recommended Air Pressure ................................................................................ 90 PSI

Sound Pressure Level ......................................................................................... 82 dBA

Length .....................................................................................................................9.4"

Net Weight ....................................................................................................... 3.6 LBS.

Chuck ......................................................................................................... 1/2" Keyed
