REMOVING THE FACTORY TRIPLE CLAMP:
Remove the brake pump.
Remove the starting number plate
(depending on model).
MOUNTING
INSTRUCTIONS
SCOPE OF SUPPLY:
1. 1× XTRIG triple clamp milled on bottom
2. 1× XTRIG triple clamp milled on top
5 3. 1× XTRIG steering stem
4. 1× tapered roller bearing
5. 8× collar screws M8×40 A/F 10
XTRIG TRIPLE CLAMP
MOUNTING INSTRUCTIONS
Certain details in these instructions may vary depen-
21 NM ding on the model. These instructions will provide
instructions for the general installation of the triple
clamp and show how to adjust the offset.
PREPARATION:
Jack up the clean motorcycle under the frame,
17 NM
lifting the front wheel off the ground.
Remove the brake line guide.
Remove the handlebar and any
fastening material such as cable ties.
Attach the brake pump to the brake line.
Remove the fender.
