VTech CS6529 Guide De Départ Rapide

Quick start guide (Canada version)
CS6529/CS6529-2/CS6529-26/
CS6529-3/CS6529-4/CS6529-5
Introduction
This quick start guide provides you with the basic installation
and setup instructions. A limited set of features are
described in abbreviated form.
You may refer to the Abridged user's manual provided in the
product package for installation and operation instructions,
or see the online Complete user's manual at
www.vtechcanada.com for complete installation and
operation instructions.
Telephone base and charger installation
Install the telephone base and charger as shown below.
Telephone wall jack
Electrical outlet
(not controlled
by a wall switch)
Telephone base
power adapter
Telephone base
Electrical outlet
(not controlled
by a wall switch)
Charger adapter
Charger
Use only the power adapters and batteries supplied with
this product.
Battery installation and charging
Install the battery as shown below. Once you have installed the
battery, you may be able to make and receive short calls. For best
performance, charge the handset battery continuously for at least
11 hours.
1. Plug the battery connector
securely into the socket.
3. Slide the battery
compartment cover towards
the center of the handset
until it clicks into place.
A DSL filter
(not included) is
required if you
have DSL
high-speed
Internet service.
The DSL filter
must be plugged
into the telephone
wall jack.
Telephone line
cord
Enter the handset menu
1. Press MENU.
2. Press or until the screen displays the desired
feature menu.
Press SELECT.
3.
• To return to the previous menu, press CANCEL.
• To return to idle mode, press and hold CANCEL.
Set date and time
Press MENU.
1.
2. Scroll to Set date/time, then press SELECT.
3. Use the dialing keys (0-9) to enter the month, date and year
and then press SELECT.
4. Use the dialing keys (0-9) to enter the hour and minute.
to select AM or PM.
Press or
5. Press SELECT.
Set number of rings
You can set the answering system to answer an incoming call
after two, three, four, five or six rings; or toll saver. With toll
saver selected, the answering system answers after two rings
when you have new messages, or after four rings when you
have no new messages.
2. Place the battery with the
1. Press MENU.
label THIS SIDE UP facing
Scroll to Answering sys, then press SELECT.
2.
up and the wires inside the
3. Scroll to Ans sys setup, then press SELECT.
battery compartment.
Scroll to # of rings, then press SELECT.
4.
5. Press
then press SELECT.
Record your own announcement
You can use the preset announcement to answer calls,
or replace it with your own recorded announcement. The
announcement can be up to 90 seconds in length.
Press MENU.
1.
4. Place the handset in the
2. Scroll to Answering sys, then press SELECT twice.
telephone base or charger
to charge. Press 7 to record.
3.
4. Speak towards the microphone after the handset announces,
"Record after the tone. Press 5 when you are done."
Press 5 when finished.
5.
IMPORTANT!
Refer to the online Complete user's manual for a full set of
installation and operation instructions. For manual download or
customer service, visit our website at www.vtechcanada.com or call
1 (800) 267-7377.
Copyright © 2012 for VTECH TELECOMMUNICATIONS LTD.
All rights reserved. Printed in China.
or to choose 6, 5, 4, 3, 2 or Toll saver,
96-008676-020-100
