Transport and storage

3.1 Overview
This chapter contains all of the information necessary for
the transportation and storage of the product and provides
an overview of the items supplied and the available
accessories for the product.
3.2 Unpacking
Open the top lid of the box
Remove the packaging materials
Unpack the contents
Check the delivery for completeness
Check the delivery for damage
3.3 Items supplied and accessories
Items supplied
The following items are included in the shipment:
Product
Power cord (in 1197250-0x, 1197251-0x, 1197252-0x)
Installation instructions
Addendum (optional)
Further information: "Notes on reading the docu-
mentation", Page 5
Accessories
The following items are optionally available and can be
ordered from HEIDENHAIN as additional accessories:
Accessories
Single-Pos stand
For rigid mounting, inclination
angle 20°
Multi-Pos holder
For fastening on an arm, continu-
ously tiltable and swivelable
Mounting frame
For mounting to a panel.
Compatible with DRO 203 and
DRO 30x products only.
Cover
For protection from dirt and
debris
KT 130 edge finder
For probing a workpiece (for
setting reference points).
Compatible with DRO 30x
products only.
IOB 610
For switching input and output
functions. Compatible with DRO
30x products only.
ACU-RITE | DRO 100, DRO 203, DRO 300 | Installation Instructions | 01/2018
3.4
3.5
Repackage and store the product carefully in accordance
with the conditions stated below.
Repackaging
Repackaging should correspond to the original packaging
as closely as possible.
Part number
1197273-01
Further information:
Page 9
1197273-02
Further information:
1197274-01
documentation", Page 6
1197275-01
283273-xx
Storage of the product
1197271-01
In case of damage in transit
Have the shipping agent confirm the damage
Keep the packaging materials for inspection
Notify the sender of the damage
Contact the distributor or machine manufacturer for
replacement parts
In case of damage in transit:
Keep the packaging materials for
inspection
Contact HEIDENHAIN or the machine
manufacturer
This applies also if damage occurred to
requested replacement parts during transit.
Repackaging and storage
Attach all mounting parts and dust protection caps to
the product or repackage them in the same way they
were originally shipped from the factory.
Repackage the product such that it is protected from
impact and vibration during transit
Repackage the product such that it is protected from
the ingress of dust or humidity
Place all accessories that were included in the
shipment in the original packaging
"Items supplied and accessories",
Include the Addendum (if it was included in the
items supplied), the Installation Instructions and the
Operating Instructions
"Storage and distribution of the
If you return the product for repair to a service
agency:
Ship the product without accessories,
without measuring devices and without
peripherals
Package the product as described above
Observe the specified ambient conditions
Inspect the product for damage after any transport or
longer storage times
