4.2.3 Mounting in a mounting frame
The mounting frame is compatible with DRO
203 and DRO 30x products only.
The mounting frame allows you to mount the product in a
panel.
Mount the rear plate of the frame to the VESA 100 tapped
holes on the rear panel of the product
Use a 2.5 mm allen wrench to tighten the screws M4
x 6 ISO 7380 included in delivery
Comply with the permissible tightening torque of 2.6
Nm
Mount the rear plate and the product to the front plate of
the frame
Use a 7 mm socket wrench to tighten the nuts M4 ISO
10511 included in delivery
Comply with the permissible tightening torque of 3.5
Nm
Mount the frame and readout in the panel
Refer to the mounting instructions provided with
the mounting frame for panel cutout and mounting
information
Further information: "E", Page 4
Dimensions of the mounting frame
Further information: "N", Page 37
4.2.4 Mounting a cover
The cover protects the product from dirt and debris.
Place the cover on the product
Place the cover over the product
Align the cover and product on the right hand side,
when viewing the front of the product
Mount the cover to the product
Remove the adhesive strip protectors from the
adhesive tabs
Fold the adhesive tabs toward the product
Press the adhesive tabs against the product securing
the tab to the product
ACU-RITE | DRO 100, DRO 203, DRO 300 | Installation Instructions | 01/2018
5 Installation
5.1 Overview
This chapter contains all the information necessary for
installing the product.
The following steps must be performed only
by qualified personnel.
Further information: "Personnel qualification", Page 7
5.2

General information

NOTICE
Engaging and disengaging connecting elements!
Risk of damage to internal components.
Do not engage or disengage any connecting
elements while the unit is under power
NOTICE
Electrostatic discharge (ESD)!
This product contains electrostatic sensitive
components that can be destroyed by electrostatic
discharge (ESD).
It is essential to observe the safety precautions for
handling ESD-sensitive components
Never touch connector pins without ensuring proper
grounding
Wear a grounded ESD wristband when handling
product connections
NOTICE
Incorrect pin assignment!
This may cause product malfunctions or damage to the
product.
Only assign pins or wires that are used
