O V E R V I E W
K E Y F E A T U R E S
The Netron RDM10 is a universal dual input RDM splitter with an advanced feature set to cover a wide variety
of applications. Its combination of a high density ten-port AB splitter with a two port EtherDMX node, DMX cue
recording plus contact closures for preset and cue recall make this a truly universal tool for installations and
production environments.
2x Input, 10x Output ports
-
RDM Splitter, HTP / LTP DMX Merge
-
2 Universe sACN and Art-Net to DMX conversion
-
Premade NETRON presets for instant setup
-
10 User Presets
-
99 Cues with Fade Time, Hold Time and Cue linking
-
External contact closures to trigger cues and preset recall
-
DMX Monitor
-
DMX and Ethernet Test Generator
-
E T H E R N E T C O N N E C T I O N
The RDM10 provides two Gigabit RJ45 connections for data input. One port supports POE 802.3af power
input, and is marked with POE on the back of the device. Both ports are connected to an internal highspeed
network switch, allowing daisy chaining of multiple devices. To avoid synchronization delays it is not
recommended to chain more than 10 devices together. The ports are auto-crossing, eliminating the need for
RJ45 crossover cables.
S O F T W A R E A N D O P E R A T I O N
This document provides safety information and mechanical installation instructions.
For setup and operation of all software features, please update the devices to the latest release. Download
and study the full user guides from http://obsidiancontrol.com/netron.
The NETRON Ether-DMX devices offer a comprehensive and easy to use feature set, and are continuously
improving. It is advised to periodically check for updates on the Obsidian product pages.
