2. Components
of the 507C meter
1
2
3
4
5
6
7
1 - Sensor connector
2 - Power switch
3 - Belt unit weight key
4 - Belt width key
5 - Up button
6 - Down button
7 - Frequency range button
8 - LCD screen with backlight
9 - Measure key
10 - Belt span length key
11 - Frequency/tension display key
12 - Data selection key
13 - Batteries
