Lighting Instructions - Real Flame Ojai Fire Column Manuel D'utilisation

Using the Ignitor
1. Read and understand all operating instructions before lighting.
2. Burner control knob must be in the OFF position.
3. Connect propane (LP) cylinder (see above pages).
4. Slowly open valve on LP gas cylinder.
5. Push and hold igniter button to create sparks.
6. While holding the igniter button with one hand, use your other
hand to push and turn the control knob to the LIGHT position
to light the burner.
7. Keep Burner Control Knob pressed in for 15-30 seconds after
ignition.
8. If ignition does not occur in 30 seconds, turn control knob to the
OFF position and turn gas off at the source, wait 5 minutes until
gas has cleared and repeat lighting procedure.
to LOW setting. Observe flame, make sure all burner ports are
lit. Flame height should be no higher than 13 inches tall.
10. Adjust the flame to the desired height with the
control knob.
!
WARNING
If burner flame goes out during operation, immediately
turn the control knob OFF and let the gas clear a
minimum of 5 minutes before attempting to re-light the
fire column.
Please refer to the trouble shooting pages for
additional support, beginning on page 16.

Lighting Instructions

15
!
WARNING
When using this method to light
your fire column use heat resistant
gloves and follow the step by step
instructions. Failure to do so could
result in severe injury.
PUSH IN
AND
TURN
