Information for the Installer

MODELL
CAPACITY
Liquid pipe diameter
Gas pipe diameter
Lenght of pipe with standard charge
Maximum distance between indoor and outdoor unit
Additional gas charge
Max. diff. in level between indoor and outdoor unit
Type of refrigerant
PIPES/
PORTS
1/4 "
(6.35 mm)
3/8 "
(9.52 mm)
1/2 "
(1.27 mm)
5/8 "
(15.88 mm)
Service port nut
Protection caps
TIGHTENING TORQUE
[N x m]
15-20
31-35
35-45
75-80
7-9
25-30
10028499 10028500
9000 BTU 12000 BTU
1/4 "
(6.35 mm) (6.35 mm)
3/8 "
( 9.52 mm) ( 9.52 mm)
3 m
15 m
20 g/m 20 g/m
5 m
410A 410A
1/4 "
3/8 "
3 m
15 m
5 m
59
