Technical Features - ROCAM VULCANO 1/1 Manuel D'instructions

• Connect the device to the grounding network through a cable which has to be
connected to the specified screw located on the external casing of the device itself.
(Component n. 12, see exploded view page 4).
To switch on the device, turn the thermostat knob on the required temperature (max 90°)
then the indicator light will turn on and when the right temperature is reached it will turn off;
through the thermostat the selected temperature will be preserved.
Turn the knob to the position "0" (OFF) to switch off the device.
WARNING:
Once turned on, the appliance will reach the desired temperature very
quickly. In order to avoid any inconvenience, turn the device on only
shortly before starting the service and turn it off shortly after the end.
Do not make any structural change to the appliance.
THE MANUFACTURER'S RESPONSABILITY AND THE PRODUCT'S WARRANTY
WILL BE CONSIDER VOID AGAINST ANY MANIPULATION MADE BY THE USER.

4.1 Technical Features

Heating
elem.warm plate
Power supply
Temperature
range
Weight (Kg)
Vulcano Vulcano
1/1 2/1
500 W 750 W
10 12
Vulcano Vulcano
3/1 4/1
2X750 W 2x750 W
230 V
30°- 90°C
16 20
Vulcano
60x40
750 W
11
3
