Tripp-Lite PDUV15 Mode D'emploi

1111 W. 35th Street
Chicago, IL 60609 USA
www.tripplite.com
Your Power Strip is designed to provide convenient multiple AC outlets. NOTE: The Power Strip
DOES NOT provide your connected equipment with surge or line noise protection.
ELECTRICAL CONNECTION
Plug your Power Strip into a standard, grounded electrical outlet. DO NOT plug your Power Strip
into 2-wire extension cords or adapters. DO NOT drill into or open any part of the housing. There
are no user-serviceable parts inside.
EQUIPMENT CONNECTION
Plug your equipment into the Power Strip's AC receptacles. DO NOT plug in equipment that draws
more total amps than your Power Strip's amperage rating (see label on Power Strip for amperage
rating), or you will trip the circuit breaker. If the circuit breaker trips, remove overload and depress
breaker to reset. Leave enough clearance at the end of the Power Strip to allow the circuit breaker to
operate normally.
Note: Select models with a power switch feature a protective switch cover. To access the switch,
simply flip open the attached cover.
HORIZONTAL MOUNTING
All standard Power Strip models feature clips for
mounting to a variety of surfaces.
1. Mark a straight, horizontal line where you
want to mount the Power Strip. At each end
of the line, mark where the edges of the
Power Strip will be located.
2. Using the supplied screws (or other ap-
propriate hardware) mount one clip at each
end of the line spaced 1 in (2.5 cm) from your
outside marks. If your Power Strip is longer
than 48 in (120 cm), mount a third clip mid-
way between the first two clips.
3. Place the Power Strip on bottom edge of
the mounting clips and snap into place.
(773) 869-1234
Copyright 2001 Tripp Lite. All rights reserved.
TRIPP LITE
POWER STRIPS
(Standard Models)
Français : p. 2; Español: p. 3
1 in.
Steps 1 & 2
Step 3
1 in.
U L
C US
