1.4. ALASKA CORNER INFRA+ parts list

Name
No. of
items
Base frame
2 Base frame
1 Base frame
1 Base frame
Wall elements
3 A/B wall elements with Multiclip
1 A/B wall element
1 A/A electrical element with Multiclip
1 A/A wall element with Multiclip
1 A/A wall element
1 A/A wall element with Multiclip
1 A/B ventilation element with Multiclip
2 A/B wall elements with heater recess
1 A/B wall element with "Infracontrol mini" recess
1 Element above the door
1 Element above the glass element
Ceiling elements
2 A/B ceiling elements
1 A/B ceiling element
1 A/A ceiling element, diagonal
Corner posts
3 90° corner posts with Multiclip
1 45° corner posts next to door with Multiclip
1 45° corner posts next to door with groove
1 Post for glass element, 8 mm groove and Multiclip
p. 6/38

Dimensions

204 x 9 x 4 cm
138 x 9 x 4 cm
61.2 x 9 x 4 cm
193 x 48 x 4 cm
193 x 48 x 4 cm
193 x 44 x 4 cm
193 x 44 x 4 cm
193 x 44 x 4 cm
193 x 55.2 x 4 cm
193 x 48 x 4 cm
193 x 48 x 4 cm
193 x 48 x 4 cm
69.3 x 10.1 x 4 cm
72.3 x 8.6 x 4 cm
194 x 48 x 4 cm
194 x 49 x 4 cm
186 x 49 x 4 cm
193 x 6 x 6 cm
202 x 7.8 x 4 cm
202 x 7.8 x 4 cm
202 x 4.5 x 4 cm
