Spare part list
Ref. No. Ordering No.
16 0663 6124 00
17 4210 1961 00
18(19-22) 4210 1930 92
19 0663 9084 00
20 0663 6124 00
21 0663 9019 00
22 -
23 4210 2009 00
24(25-29) 4210 1929 91
25 -
26 -
27 -
28 -
29 0335 1100 02
30 4210 1815 01
31 4090 0227 00
32 4210 1857 00
33 -
34 -
35 -
Motor
1
Ref. No. Ordering No.
1 4111 0107 00
2 4111 0128 00
3 0502 0107 00
4(5-6) 4210 1908 90
5 -
6 0337 2515 00
7 4210 1896 00
8 -
9 4210 0324 00
10(11-14) 4210 1858 90
11 0101 1149 00
12 -
13 4250 0766 00
14 4250 0778 00
15 0502 0155 00
Gear
1
Ref. No. Ordering No.
1 0335 2133 00
2 4111 0121 00
62
Qty Description
1 O-ring
1 Adapter
1 Exhaust kit
1 O-ring
1 O-ring
1 O-ring
1 Exhaust casing
1 Tube
1 Deflector, compl.
1 O-ring
1 Silencer
1 Filter
1 Exhaust deflector
1 Circlip
1 Reversing valve
1 O-ring
1 Reversing knob
1 Screw
1 Data plate
4 Screw
4
2 3 5 6 8
Qty Description
1 Washer
1 Spring
1 Ball bearing
1 End plate, compl.
1 End plate
1 Key
1 Rotor
5 Vane
1 Cylinder
1 End plate, compl.
1 Pin
1 End plate
1 Spring
1 Pin
1 Ball bearing
4
5 6 7
2 3
Qty Description
1 Circlip
1 Nut
© Atlas Copco Tools - 9836 4060 00
Remark / Included in Service kit
17.1x1.6
G 1/4". With NPT-thread (for the US and Canada) 4210 1961 01
17.5x3
17.1x1.6
14x1.2
22.22x2.62
21x2 / Service kit 4081 0053 90
K25 2.5x14 / Service kit 4081 0053 90, Small parts kit 4081 0055 90
3x1.5
10
7 9 11 12 13 14
Remark / Included in Service kit
607 / Motor unit kit 4081 0054 90
R2x2x12
Motor unit kit 4081 0054 90
CP 2h6x6
625-Z / Motor unit kit 4081 0054 90
8
9
Remark / Included in Service kit
SgH 32
15
= Included in
Service Kit
12
10 11 13 14 15 16
D2148-RQ
