FLOAT IN RAISED POSITION
FIG. 3
FIG. 4
FIG. 5
•
With the power head in an upside down position, slide the
cartridge filter down over the filter cage, push the filter seals
against the power head.
• Place filter retainer into the top of the cartridge filter, hold
the power head with one hand, turn the handle on the filter
retainer clockwise to tighten, locking the filter into place.
• To remove the cartridge filter for cleaning, again hold the
power head and turn the filter retainer counter-clockwise
to loosen and remove, slide the cartridge filter off the filter
cage.
• To clean the cartridge filter shake or brush off excess dirt or
rinse (from the inside of the filter) with water, dry completely
(approximately 24 hours) and re-install.

WET PICK UP

•
Remove cartridge filter and replace it with foam filter when
you do wet pickups.
•
This wet/dry vac is equipped with a float mechanism which
will rise automatically to cut off the airflow when the liquid in
the tank reaches a predetermined level. When this happens,
turn off the vac, remove the battery, and empty the dust
tank. You will know that the float has shut the airflow off
because the suction ceases and the motor noise becomes
higher in pitch due to increased motor speed. The liquid
capacity may vary with the rate of pickup. (Fig. 3)

EMPTYING THE TANK

WARNING: To reduce the risk of injury from accidental starting,
remove the battery before emptying the dust tank.
•
Remove the power head assembly of the wet/dry vac by
pulling outward on the lid clips located on each side of the
vac. Lift off the power head assembly. (Fig. 4)
•
Dump the tank contents into the proper waste disposal
container.

BLOWING OPERATION

WARNING: To reduce the risk of injury from accidental starting,
remove the battery before changing. To avoid injury to bystanders,
keep them clear of blowing debris.
CAUTION: Wear a dust mask if blowing creates dust which
might be inhaled. To reduce the risk of hearing damage, wear ear
protectors when using the vac/blower for extended hours or when
using it in a noisy area.
Your vac contains a blowing feature. It has the capability to blow
sawdust and other debris. It can be used to blow dust and debris
out of garages or off patios and driveways. Follow the steps below
to use your vac as a blower.
•
Locate blowing port on your vac.
• Insert one end of the hose into the blowing port. (Fig. 5)
• Turn vac "ON".
