ASSEMBLY
To install/remove the battery
To install the battery insert firmly into the tool until you hear an
audible click, ensuring the battery is fully seated and latched
into position.
To remove the battery depress the battery release button and
pull the battery out of the tool.
Attaching the vacuum hose (fig1)
Before using the vacuum the flexible hose will need to be
attached.
•
Ensure the vacuum is placed on a flat, firm surface.
•
Unlatch tank latches and remove power head from the tank.
•
Remove the hose from the tank.
•
Align the latching end of the hose with the intake or blower
port on the appliance, ensuring the alignment lock is
correctly orientated to fit into the port.
• Insert the hose end into the port until you hear an audible
click. Gently pull the hose end to ensure it is correctly
secured.
• Replace power head onto the tank and secure latches.
Note: The power head will only fit onto the tank when the
intake port on the front of the power head and the storage
area for the wide nozzle tool on the tank are aligned.
Note: To reduce the risk of injury always hold securely with one
hand on the main handle. (1)
OPERATING INSTRUCTIONS
WARNING: To reduce the risk of fire or explosion, do not operate
this vac in areas with flammable gases, vapors or explosive
dust in the air. Flammable gases or vapors include but are not
limited to: lighter fluid, solvent-type cleaners, oil-based paints,
gasoline, alcohol or aerosol sprays. Explosive dusts include
but are not limited to: coal, magnesium, aluminium, and grain
or gun powder. Do not vacuum explosive dust, flammable or
combustible liquids or hot ashes. Do not use this vac as a sprayer
for any flammable or combustible liquid. To reduce the risk
of health hazards from vapors or dusts, do not vacuum toxic
materials.
CAUTION: To reduce risk of hearing damage, wear ear protectors
when using the vac for extended hours or when using it in a
noisy area. This 11L wet/dry vac is assembled at the factory and
ready for use when you remove it from the packaging. The unit is
ready for dry vacuuming or blowing.
ON/OFF
After you insert the battery into the machine, turn the unit "ON"
by pushing the switch from position "O" to position "I". The "O" is
the "OFF" position and the "I" is the "ON" position.
DRY PICK UP
NOTE: If foam filter is in position over filter cage, it must be
removed before installing cartridge filter. The cartridge filter can
be used for wet or dry pick up; installation is the same for both.
When picking up large quantities of liquid please refer to the wet
pick up operation section in this manual. Use the cartridge filter
in position over the filter cage for most general dry material pick
up. (Fig. 2)
www.evolutionpowertools.com
FIG. 1
FIG. 2
