Battery replacement

NOTE: Please contact After Sales Service from Gre before any battery replacement.
1.Pull out the four clips of the core part of the upper cover outward and separate it from the body assembly of the bottom
cover.
4. According to the disassembly steps, re install the battery and assemble the charging parts.
Note:
(1) if there are impurities in the seal ring, clean it and install it back into the seal ring groove.
(2) Pay attention to the assembly direction. The six screw holes must be aligned to lock the screws.
TROUBLE SHOOTING
If you have problems with your cleaner, follow the troubleshooting steps below to restore performance. Note: turn off the
power before making any repairs.
PROBLEM
Robots don't capture debris.
The robot stops moving in the middle
of the pool (the rotating head is still
turning).

POSSIBLE CAUSES

The battery is low.
Impeller stuck.
Impeller damaged.
The glove box is full.
The robot was stopped by an obstacle.
The robot is blocked by the suction of
the main pool floor drain.
The ground is not totally flat
2. Use a screwdriver to remove
all screws on the power cover of
the bottom cover.
3. Open the battery cover, find the
battery connection line, press the
clip on the connector, pull it out, and
take out the battery.
Note: wrap the connector with in-
sulating tape immediately to avoid
short circuit caused by contact
between two wire terminals.
SOLUTION
Then charge the robot.
Turn off the power supply of the
robot and visually check whether the
impeller rotates. If necessary, contact
your dealer for further instructions.
Warning! Before servicing the
equipment, make sure that the robot is
turned off.
Please contact your dealer for
replacement.
Clean the glove box and filter cover.
Check the cleaner for obstructions.
Remove obstacles.
Turn off the filtration system (see
instructions in the manual).
It takes more minutes before moving
again or Make the bottom of the pool
flat or trim the bottom brush strip.
Contact your dealer for replacement
parts.
