ASSEMBLY
A: Floater
B: Upper cover
B-1: Jet head
C: Filter
D: Bottom base
E: Charger
There is a rotation jet head at the upper cover, the water is passing from bottom to the jet head to make the robot moving.
While facing obstacle, the jet head turns around 180 degrees, the robot rounds the obstacle and moving by another line.
The rubbish is collected and installed by the bottom filter cabine.

ASSEMBLY AND OPERATION

Charging warning
• Use only the original external adapter and the charging cable provided.
• Make sure the robot and charger ports are clean and dry before installation.
• Power up the robot before using it for the first time (about 4-5 hours)
Note:
Once the robot starts charging, the indicator light on the external adapter will turn red. When the robot is fully charged,
the indicator light will turn green.
Power on
1
Turn on the switch, loosen the rope on the float, put the
robot horizontally into the pool, and wait for the robot to
sink freely to the bottom. (if the product is not put into the
water, the machine will not rotate because the machine
has the function of "stop when leaving water").
INSTRUCTION MANUAL
A
E
B
C
D
B-1
Switc h
Charging port
2
Adjust the length of the rope to ensure that the length of
the rope is at the same height as the water level, and the
extra length of the rope is tied or cut short.
Bottom cover body assembly bottom
