HOOKUP DIAGRAM

Refer to the possible connection scenario for hooking up the DESK ROCKER USB
speakers.
LAPTOP
POWER
SOURCE

FRONT PANEL OVERVIEW

2
CD PLAYER OR
OTHER DEVICE
1. VOL/POWER – This knob is used to turn the
speakers on and adjust their volume. To turn on,
simply turn up the knob; you will feel a click when
the speakers turn on. A blue LED light on the left
side of the speaker will illuminate.
simply turn the volume all the way down; the blue
LED will turn off to let you know that the speakers
are off.
2. HEADPHONES – Connect your 1/8" headphones
to this output to hear the mix through your
headphones. Note that while the headphones are
connected, you will not be able to hear sound out
of your speakers until the headphones are
disconnected.
1
2
TURNTABLE OR
OTHER DEVICE
To turn off,
