Omcan MG-CN-0010 Manuel D'instructions page 13

Model MG-CN-0010
Item No. Description
19992 Cap for SM-G50
20049 Stuffer Tubes Kit for SM-G50
19990 Cutting Plate (Coarse) for SM-G50
19988 Cutting Plate (Fine) for SM-G50
19989 Cutting Plate (Medium) for SM-G50
19991 Kubbe Attachment Kit for SM-G50
19987 Cutting Blade for SM-G50
19985 Head for SM-G50
19984 Hopper Plate for SM-G50
19983 Food Pusher for SM-G50
19982 Opening for SM-G50
19980 Locking Knob for SM-G50
42184 Self-Tap Bolt 4x10-VCr for SM-G50
27144 Cover for SM-G50
27178 Switch Panel for SM-G50
42172 Cord Compartment Cover for SM-G50
31607 Supply Cord for SM-G50
19981 Motor Housing for SM-G50
19979 Switch for SM-G50
42186 Self-Tap Bolt 4x10 for SM-G50
21640
Position Item No. Description
1 27145 Bolt Seat for SM-G50
2 - 5 42187 Self-Tap Bolt 4x20 for SM-G50
6 42188 Cord Compartment for SM-G50
Terminal Block PA10
7 42189
(Only for G50-EMC) for SM-G50
Resistance 1MΩ0.25W
8 42190
(Only for G50-EMC) for SM-G50
Capacitance 0.22μF
9 - 10 42191
(Only for G50-EMC) for SM-G50
11 42192 Bottom Board for SM-G50
12 27146 Rubber Underlay for SM-G50
13 19986 Feed Screw Assembly for SM-G50
14 42769 Feed Screw for SM-G50
15 42193 Washer 16x0.2 for SM-G50
16 42194 POM Washer for SM-G50
17 42195 Washer16x1.5 for SM-G50
18 42196 Wire Loop for SM-G50
19 42197 Gearbox Assembly for SM-G50
20 42198 Fan for SM-G50
21 42199 Motor for SM-G50
22 42200 Quakeproof Washer for SM-G50
23 42201 Insulated Washer for SM-G50
24 42202 Bolt M5x12 for SM-G50
Parts Breakdown
Position Item No.
25 42203
26 42204
27 39877
28 39878
29 39879
30 24557
31 39880
32 24558
100 42205
101 27171
102 42206
103 42207
104 42208
105 42209
200 42210
201 42211
202 42212
203 42213
204 40657
205
13
Description Position
Back-Gearbox for SM-G50 206
Washer 10x0.5 for SM-G50 207
10 Shaft for SM-G50 208
8 Shaft for SM-G50 209
Washer 8x0.5 for SM-G50 210
Bevel Wheel for SM-G50 211
Sleeve for SM-G50 212
Coupled Gear for SM-G50 213
Spring Ring 12 for SM-G50 214
52 Gear Wheel for SM-G50 215
Washer 12x0.5 for SM-G50 216
Washer 12x0.2 for SM-G50 217
Fore-Gearbox for SM-G50 218
Washer 5 for SM-G50 219
Spring Washer 5 for SM-G50 220
Bolt M5x12 for SM-G50 221
12 Bushing for SM-G50 222
13 Shaft for SM-G50 223
Power Wire Protection Ring for SM-G50
