Wiring Diagram
POWER/INTERNET BOARD
ON
RADIO ANTENNA
yellow
white
green
black
DOOR BOARD
white
red
red
black
white
purple
black
white
purple
blue
green
yellow
orange
9
10
black
green
white
yellow
DOOR BOARD
Not responsible for conflicts between the information listed in
the wiring diagram and the requirements of your local building
codes. The information is for suggested use ONLY. Check your
local codes BEFORE installation.
red
1 - Red
7
5
3
1
2 - Orange
8
6
4
2
3 - Yellow
4 - Green
5 - Blue
6 - Purple
7 - Not used
8 - White
9 - Black
10 - Not used
24
orange
blue
1 - Red
2 - Orange
3 - Yellow
4 - Blue
5 - Green
6 - Purple
7 - Not used
8 - White
9 - Black
10 - Not used
2
4
1
3
MICROPHONE
Wi-Fi
®
ANTENNA
6
8
10
5
7
9
SENSOR
BOARD
black
red
white
POSTAL LOCK SWITCH
SPEAKER
