ENGLISH
Section 1. Safety Information .......................... 3
Section 2. Product Description and Model
Numbers .......................................... 4
Section 3. Installing Jandy Light Fixture during
New Construction ........................... 5
3.1 Preparing the Light Fixture for Installation .......... 5
3.2 Installing the Light Fixture ................................. 6
Section 4. Replacing Jandy Light Fixture in an
Existing Pool or Spa ....................... 6
4.1 Preparing the Light Fixture for Replacement ...... 6
4.2 Replacing the Light Fixture ................................ 7
Section 5. Wiring Options for Controlling Jandy
WaterColors RGBW LED Lights .... 8
5.1 Wiring to an AquaLink
5.2 Wiring to a Time Clock ....................................... 8
5.3 Wiring to a Switch ............................................... 8
Jandy Pro Series, WaterColors RGBW LED Lights
®
Table of Contents
RS Control System ....... 8
®
|
Installation Manual
Section 6. Jandy WaterColors RGBW LED Light
Operating Instructions ................... 8
6.1 To Operate the Light and Change Colors ........... 8
6.2 To Reset to the Beginning of the Color
Sequence ......................................................... 10
Section 7. Replacing Light Engine (PCB) ..... 10
7.1 Pool Clamp Removal ........................................ 10
7.2 12V Small Light Driver (PCB) Replacement ..... 10
7.3 120V Small LED Board Replacement ...............11
7.4 120V Small Light Driver (PCB) Replacement ....11
7.5 Large Light Driver (PCB) Replacement
(120V and 12V) .................................................11
7.6 Reassemble the Fixture ....................................11
7.7 Reinstall the Jandy Pro Series Light into
Niche Fixture .................................................... 13
Section 8. Twelve (12) Volt Installation ......... 13
Section 9. Exploded View and Replacemen
Parts ............................................... 14
9.1 Jandy Large WaterColors RGBW LED Light .... 14
9.2 Jandy Small WaterColors RGBW LED Light .... 15
