USB 3.0 DisplayPort Adapter
Installation Guide
Installationsanleitung
Manuel d'utilisateur
Manuale d'uso
www.LINDY.com
For Home and Office Use
Tested to Comply with
FCC Standards
© LINDY ELECTRONICS LIMITED & LINDY-ELEKTRONIK GMBH – First EDITION (DECEMBER 2011)
Introduction
Thank you for buying the LINDY USB 3.0 DisplayPort Adapter. This
adapter allows you to connect any monitor with DisplayPort connector to
your PC or notebook. Thanks to SuperSpeed USB 3.0 and DisplayLink
Technology, there is no need to add an additional graphics cards to your
computer!
This additional monitor can be used as an additional standard Windows
monitor in mirror mode or extended desktop mode. It also can be config-
ured to be used as a primary monitor.
It can be used to output a high resolution standard Windows desktop as
well as for video playback using Windows Media Player or appropriate
software that supports Video playback on an extended desktop.
Features
USB connectivity between PC/notebook to additional display monitor
via DisplayPort connector.
Supports mirror, extended and primary display modes.
SuperSpeed USB 3.0 delivers higher resolution and performance for
video and 3D graphics
Next generation DisplayLinkTM (DL3.0) compression technology
Equipped with USB to DisplayPort audio device to transfer the audio
from PC to a monitor
Supports high resolutions up to 1920x1080p (Full HD) and 2560x1600.
24-bit colour depth for high quality graphics
Display your PC contents (Internet, music, photo, and video as sup-
ported by your PC) to a monitor with DisplayPort.
Add up to six displays per PC (dependent upon PC specification)
Supports standard (4:3) and widescreen (16:9,16:10) aspect ratios
Automatic display detection using VESA compliant protocols
Supports the following media players for video play: Windows media
player 12, Win DVD8, Power DVD 7, Real Player 11
No. 43171
E n g l i s h
E n g l i s h
English
Deutsch
Français
Italiano
IMPORTANT NOTE:
You must install the driver from the CD
before attaching the USB 3.0 to
DisplayPort Adapter to your computer!
WICHTIGER HINWEIS:
Sie müssen die Treiber von der
beiliegenden CD installieren bevor Sie
den Adapter anschließen!
NOTE IMPORTANTE:
Vous devez installer le pilote du CD
avant de connecter l'adaptateur USB
vers DisplayPort à votre ordinateur!
IMPORTANTE:
Occorre installare prima i driver dal CD
incluso nella fornitura prima di collegare
l'adattatore USB/DisplayPort al
computer!
Supported Resolution Table
Resolution
Name
640x480
VGA
720x480
768x567
800x600
SVGA
832x624
800x480
848x480
1024x600
1024x768
XGA
1152x864
1152x870
1280x720
720p
1280x768
WXGA+
1280x800
WXGA
1280x960
1280x1024
SXGA
1360x768
1366x768
WXGA+
1368x768
1400x1050
SXGA+
1440x900
1600x900
1600x1200
UXGA
1680x1050
WSXGA+
1920x1080
1080p
1920x1200
WUXGA
2048x1152
2048x1280
2048x1536
2560x1440
2560x1600
WQXGA
Refresh Name
60 67 72 75 85
70 85 88
50 60
56 60 72 75 85
75
60
60
60
60 70 75 85
75
75
50 60
60 75 85
60
60 85
60 75
60
50 60
60
60 75 85
60
60
60
60
50 60
60
60
60
60
60
60
