until the appliance has adjusted to the
temperature and is completely dry be-
fore operating it. The acclimatization
period depends on the temperature dif-
ference and the type and design of the
appliance. However, it should be at least
12 hours.
Connecting the power supply
Check that the rated voltage indicated
on the appliance matches the mains
voltage in your area. Connection to the
incorrect voltage will damage or destroy
the appliance.
Before switching on the appliance,
check that all cables and lines are prop-
erly fitted and undamaged. Make sure in
particular that there are no kinks in the
cables, that they are not pulled too
tightly around corners and that no ob-
jects are resting on them. Also make
sure that all plug connections are se-
curely inserted. Faulty shielding or wir-
ing poses a health hazard (electric
shock) and can destroy other appli-
ances. Appliances with mains plugs are
fitted with a safety-tested mains cable
for the respective country of use and
may only be connected to a correctly
earthed safety socket. Otherwise, there
is a risk of electric shock. Make sure
that the socket on the appliance or the
domestic safety socket is easily accessi-
ble so that the mains cable can be un-
plugged from the socket in an emer-
gency or during servicing and mainte-
nance work.
Danger of electric shock!
Do not clean the hood with a steam
cleaner or water pressure cleaner. The
hood must be disconnected from the
power supply prior to cleaning.
General method of operation
The extractor hood has been especially
developed for the extraction of cooking
vapours in private households. The ris-
ing cooking vapours are captured by the
extractor hood and sucked out through
an internal frame via internal metal fil-
ters. The metal filters are held in the
22
hood body by means of magnets. This
type of extraction uses ultra-effective
centralised internal extraction. The
metal filters in these hood models are
easily accessible from below and can be
removed without the need for tools. The
extraction capacity is controlled via the
control panel. In addition to the lighting,
which is sunk discreetly into the central
panelling, the control panel also controls
additional functions. The illumination of
the hob is provided by several halogen
spot lights.
2
3
1
Product description
1 Hood body
2 Tower
3 Control panel
4 Metal filters
5 Lighting (internal)
The control panel consists of 7 buttons.
Fan power
The first four buttons control the fan
power:
Button "1"
= low fan power
Button "2"
= medium fan power
Button "3"
= high fan power
Button "Int"
= Intensive setting
Press any button to switch on the appli-
ance. Press the backlit button to switch
5
4
