Part Names

19
E E E E
17 18
20
1
2
3
4
5
6
7
8
10. Anti-tip stubs
9
12. Upper level
10
11
13. Lower level
12
14. Door hinges
13
14
15. Latches
15
16. Air deflector
16
18. Door gasket
ACCESSORIES
20. 2 Racks
8 8 8
1. Air vent opening
2. Handle
3. LCD display
4. Control panel
5. Frame
6. Drip tray (see page 10)
7. Reservoir lid (see page 10)
8. Reservoir (see page 10)
9. Oven light
11. Tray guide
17. Ceramic oven floor
19. 2 Trays
