6 Changing the Batteries

6.1 Battery Replacement Procedure

Batteries should be changed when the
icon will remain lit until the batteries are changed. If the battery
power level is too low the Check O
the batteries are changed.
1176119-A
icon illuminates. The
Plus will not power on until
2
1. Using a #1 Phillips screwdriver loosen the battery door screw A
and remove the battery door B.
2. Remove the batteries.
3. Insert new batteries ensuring correct polarity. DO NOT use
rechargeable batteries.
4. Replace the battery door and tighten the battery door screw.
5. If the Check O Plus does not power on when done verify the
2
batteries are installed correctly and that the batteries are fresh.
Changing the Batteries
13
