Connecting the other external components

You can connect an external component to the auxiliary input jack on the control panel (F-AUX)
and/or on the rear side of the unit (R-AUX).
Summary of using the external components through the auxiliary input jacks:
Auxiliary
External component
input jack
Portable audio Front
player
Rear
Bluetooth device Rear
* "BT PHONE" appears when a Bluetooth phone is in use.
On the control panel (F-AUX):

Listening to the other external components

For details, refer also to the instructions supplied with the external components.
~
] "F-AUX" or "R-AUX"
Preparation
Menu setting
item
SRC SELECT F-AUX ON
SRC SELECT R-AUX ON
SRC SELECT R-AUX BT ADAPTER BT AUDIO/
3.5 mm (1/8")
stereo mini plug
(not supplied)
Portable audio player,
etc.
Recommended to use a 3-terminal plug head stereo mini plug for
optimum audio output.
Turn on the connected component and
Ÿ
start playing the source.
Sub-
Setting
item
F-AUX
R-AUX
BT PHONE *
On the rear panel (R-AUX):
Connecting
Source
cable/device
name
(not supplied)
See below.
KS-BTA100
(page 14)
3.5 mm (1/8") stereo mini
plug (with "L" shaped
connector) (not supplied)
Portable audio player,
etc.
