• Odkręcić zderzak.
• Odkręcić belkę zderzeniową ( nie będzie już potrzebna)
• Wsunąć belkę haka do podłużnic i skręcić śrubami M10x35 8.8 ( pkt.1)
• Wyciąć fragment o wymiarach 60x90 w dolnej części zderzaka,
w jego osi, 45 mm od dolnej krawędzi zderzaka.
• Założyć zderzak.
• Przykręcić kulę i blachę gniazda elektrycznego śrubami M12x70 8.8.
• Dokręcić wszystkie śruby z momentem wg tabeli.
• Podłączyć instalację elektryczną.
• Unscrew the bumper.
• Unscrew the bumper bar (it will not be used any more).
• Insert the main bar A in the frame side members and
screw with bolts M10x35 8.8 (pkt 1).
• Cut out the fragment 60x90 in the lower part of the bumper, in its axle,
45 mm from the lower edge of the bumper.
• Tighten all the bolts according to the torque setting- see the table.
• Assemble the damper and its rear reinforcement.
• Fix the ball and electric plate with bolts M12x70 8.8.
• Connect the electric wires.
• Dévisser le pare-chocs.
• Dévisser la poutre de chocs (elle ne sera plus utilisée).
• Inserer la poutre du crochet d'attelage dans les
longerons et serrer avec les boulons M10x35 8.8 (point 1).
• Dans la partie inférieure du pare-chocs, dans son axe,
couper un fragment aux dimensions 60x90, environ 45 mm
du bord inférieur du pare-chocs.
• Monter le pare-chocs.
• Visser le crochet d'attelage et socle de prise électrique à l'aide des
boulons M12x70 8.8.
• Serrer tous les boulons avec un couple de serrage selon tableau.
• Raccorder le circuit électrique.
