3

Description

3.1

Scope of delivery

The AQUATEC R / AQUATEC F / AQUATEC XL is
supplied with the following parts (fig. 1 to fig. 3):
Seat (fig. 1) consisting of:
1 Sideflap
2 Seat plate
3 Hinge for backrest
4 Lifting scissors
5 Spindle foot retainer
6 Rear suction cup (double strap with thread)
7 Base plate
8 Guide for gliding shoe
9 Gliding shoe
10 Front suction cup (single strap with head)
Backrest (fig. 2) consisting of:
1 Jack plug
2 Drive
3 Spindle foot
4 Lock pin
5 Backrest plate
Hand control and charger (fig. 3)
1 Hand control and curled cable
3 Charger
The battery is built into the hand control.
Operating instructions (not illustrated)
3.2

Technical data

Bathlift
Seat length:
Seat width with sideflaps folded out:
Seat width with sideflaps folded in:
Seat height at lowest position:
Seat height at highest position:
Max. load (AQUATEC R / AQUATEC F):
Max. load (AQUATEC XL):
Total weight without hand control:
Seat weight:
Backrest weight:
Hand control weight:
Charger weight:
Operating voltage:
Rated current:
Battery type:
Charger input:
Charger output:
Charge time as from low-voltage warning: approx. 4 h
EN
590 mm
715 mm
420 mm
60 mm
420 mm
135 kg
170 kg
12.1 kg
7.5 kg
4.6 kg
0.43 kg
0.1 kg
14 V
4 A
LiIon
230-240 V AC, 50 Hz
24 V DC, 135 mA, 3 VA
The label (for example, fig. 11) provides important
information:
1 Conformance code
2 Duty cycle
3 Instruction (disposal)
4 Degree of protection
5 Serial number
6 Last digits of year of production
7 Plant
8 Type B application unit
9 Instruction (observe accompanying documents)
10 Period of production
11 Rated voltage/consumption
12 Load capacity
The label is on the rear side of the backrest.
4

Transport

Important!
●
The backrest is not locked on the seat
when it is folded together.
● Do not remove the suction cups when
transporting the bathlift.
●
The hand control must be removed from
the backrest for transport.
Remove the hand control and always disassemble the
bathlift into two sections for transport (the seat and the
backrest).
For detailed instructions on how to dismantle the de-
vice, please refer to section 5.3.
5

Setting up

Important!
●
Before setting up, inspect all parts for dam-
age caused by transport.
● During assembly, make sure the parts are
positioned correctly in relation to each
other.
5.1

Recharging the battery

CAUTION!
There is a risk of injury from electric shock.
Only recharge the battery in dry rooms (not
in the bathroom).
