WIRING: RGL300 with RP2000 / COMPACT
Yellow ring control for telephone line
In all cases
RJ11
to RGL300
Control with RMT2001 channel (RP2000 or COMPACT II) .
Requires a 24V power supply.
RJ45
to RGL300
Rami - RGL300
RJ45
ASM110
Configure internal JP7 on line and microphone.
See the RP2000 manual or COMPACT II manual.
1 2 3 4 5 6
+24V
GND
11
next
RJ11
to telephone line
RMT2001 Remote
15 pts mâle plug
1
9
5
13
6
15
8
PS
24V
230V
ENGLISH
