5) Programming
With a pilot wire:
The appliance can be controlled remotely if its pilot wire is connected to an appliance fitted with a pro-
grammer, to a central programming unit or to an energy control system.
Chart indicating the orders the device can receive over its pilot wire
Orders received Current absent
Ref/neutral
oscilloscope
Mode achieved
Heating
temperature
With a separate programmer:
The appliance can also be programmed independently by inserting a programmer in the
housing at the rear of the control box.This programmer will create the ECO and COM-
FORT modes just as you have defined them for your appliance.
This device enables holding, heating, and drying your towels.
It also enables heating your bathroom. For optimum heating, please do not obstruct the
air outlets of the device.
1) Description of the control panel
2) Setting the CONFORT temperature
It is the temperature desired when the room is occupied.
a) Set the switch to
b) Align the toothed screw
is less than desired.
Wait a few hours for the temperature to stabilise.
If the temperature setting does not suit you, adjust it using the adjusting screw
using the notches (one notch at a time).
The thermostat's cycle takes several minutes. It is possible that the heating indicator may not react ins-
tan- taneously, but instead only on the next thermostat cycle.
(to be measured between the pilot wire and the neutral).
Full alternance
230V
CONFORT ECO
3°C to 4°C
CONFORT below
setting CONFORT
setting
U
SING THE DEVICE
to the ON position, the
with the marking
Negative half- Positive half-
alternance alternance
-115V
STOP LOAD
STANDBY
SHEDDING
Instant device
Standby
stop. Can also
temperature,
be used for load
about 7°C
shedding.
Temperature setting knob with HorsGel
position.
Time adjustment knob TURBO 1/4h, 1/2h, 1h, 2h.
Power On indicator
TURBO indicator
TURBO control
ON/OFF switch
Heating indicator
indicator lights.
: the indicator light
+115V
illuminates if the temperature
. Proceed step-by-step
