Monomat
Time switch
User guide
Monomat
Thank you for choosing the Monomat time swit-
ch which allows you to switch on an electric cir-
cuit at various time-periods of the day.
Two versions
Without running reserve:
ref. 10001
With running reserve:
ref. 10002
View of switch
1.
Programming disc
2.
Electrical connections
3.
Override switch for permanent operation
4.
Time-setting mark
5.
Direction of rotation of programming disc.
2
4
~ M
3
1
5
7
8
4
9
10
1 0
3
1
MONOMAT
2
4
2
1
3
To programme your time
switch
To program the times of switching on/off:
³
Move the disc to the time period which you
wish to programme
·
push the segments corresponding to the "swit-
ch-on" time towards the left (red-zone= swit-
ched on)
1
To read the programme
Turn the programming disc in the direction indi-
cated by the arrow.
Setting the time
Turn the programming disc in the direction indi-
cated by the arrow.
Set the time of day or night opposite the mark.
Permanent operation
1
For permanent operation you simply put the swit-
ch in this position
1
To return to automatic switching, put the switch
in this position
1
e.g. 8.45 - 10 switched off
8
e.g. 10 - 11 switched on
9
10
11
1 0
MONOMAT
7
8
e.g. 10 A.M.
9
10
1 0
1
MONOMAT
I
.
Installation guide
1
7
8
9
10
1 0
1
MONOMAT
Appliance
2
4
1
3
Dimensions
2
Technical specifications
• Supply voltage:
230 V ±10% 50/60 Hz.
• Power reserve:
200 h after 120 h of supply.
• Output:
Normally Open contact.
• Switching capacity:
resistive load:
16 A / 250 V AC.
inductive load:
4 A / 250 V AC cos ϕ = 0,6.
• Accuracy:
1 sec. / 24 h. to 20°C.
• Operating temperature:
– 10° C to + 55° C.
• Storage temperature:
– 20° C to + 65° C.
• Max humidity :
• Protection class:
• Insulation class:
• Connection
tunnel terminals, conductor cross-section:
• Conformity with
• CE marking
95 % at 30° C.
IP 30.
II.
max. 6 mm
.
2
min. 1 mm
2
.
EN 60730.
yes.
