GA-H55M-S2 Motherboard Block Diagram

1 PCI Express x16
CPU CLK+/- (133 MHz)
DDR3 1666 (O.C.)/1333/1066/800 MHz
LGA1156
Mémoire à canal double
Processeur
PCIe CLK
(100 MHz)
x16
Bus PCI Express
1 PCI Express x1
LAN
D-Sub
RJ45
PCIe CLK Dual BIOS
Realtek
(100 MHz)
RTL8111E
6 SATA 3Go/s
Intel H55
x1
x1
®
Bus PCI Express
12 Ports USB
Bus PCI
LPC
Bus
iTE
IT8720
CODEC
Souris/Clavier PS/2
2 PCI
PCI CLK
(33 MHz)
- 8 -
