Sauder Shoal Creek Serie Mode D'emploi
Masquer les pouces Voir aussi pour Shoal Creek Serie:

Publicité

Liens rapides

sauder.com
Desk
Shoal Creek Collection | Model 409733
Need help? Visit Sauder.com to view video assembly tips or chat with a live rep.
Prefer the phone? Call 1-800-523-3987.
Share your journey!
The original desktop.
NOTE: THIS INSTRUCTION
BOOKLET CONTAINS IMPORTANT
SAFETY INFORMATION.
PLEASE READ AND KEEP FOR
FUTURE REFERENCE.
English pg 1-25
Français pg 26-28
Español pg 29-32
Lot # 502115
02/28/17
Purchased: __________________
Be sure to give us a ring before
making any returns. 1-800-523-3987

Publicité

loading

Sommaire des Matières pour Sauder Shoal Creek Serie

  • Page 1 Shoal Creek Collection | Model 409733 NOTE: THIS INSTRUCTION BOOKLET CONTAINS IMPORTANT SAFETY INFORMATION. Need help? Visit Sauder.com to view video assembly tips or chat with a live rep. PLEASE READ AND KEEP FOR FUTURE REFERENCE. Prefer the phone? Call 1-800-523-3987.
  • Page 2 HUTCH LEFT END (1) LEFT DRAWER SIDE (1) RIGHT FRONT/LEFT REAR LEG (2) HUTCH UPRIGHT (1) DRAWER BACK (1) LEFT FRONT/RIGHT REAR LEG (2) HUTCH SHELF (1) LARGE DRAWER BACK (1) PENCIL DRAWER FRONT (1) HUTCH BACK (1) Page 2 409733 www.sauder.com/services...
  • Page 3 Part Identifi cation D716 D121 D726 D716 www.sauder.com/services 409733 Page 3...
  • Page 4 3S GOLD 5/16" FLAT HEAD SCREW - 24 BLACK 1-1/8" PAN HEAD SCREW - 4 15S SILVER 5/8" MACHINE SCREW - 6 30S BLACK 1-9/16" FLAT HEAD SCREW - 13 BLACK 9/16" FLAT HEAD SCREW - 4 BLACK 7/8" MACHINE SCREW - 1 Page 4 409733 www.sauder.com/services...
  • Page 5 Look for this icon. It means a Step 1 video assembly tip is available at www.sauder.com/services/tips Assemble your unit on a carpeted fl oor or on the empty å carton to avoid scratching your unit or the fl oor. Scan this QR code or go to this address: http://qr.sauder.com/?ID=1739...
  • Page 6 Step 2 Turn thirteen CAM SCREWS (8F) into the LEGS (G å and H) and PENCIL DRAWER FRONT (I). (13 used) Page 6 409733 www.sauder.com/services...
  • Page 7 Edge with CAM DOWELS Shoulder These edges Apply pressure with your hands as should be even. you guide the MOLDINGS over the SCREWS and onto the ENDS. BLACK 9/16" FLAT HEAD SCREW (4 used in this step) www.sauder.com/services 409733 Page 7...
  • Page 8 Step 4 Fasten the LEGS (G and H) to the ENDS (A2 and B2). å Tighten twelve HIDDEN CAMS. These surfaces should be even. Angled edge These surfaces should be even. Angled edge Page 8 409733 www.sauder.com/services...
  • Page 9 Use twelve GOLD 5/16" FLAT HEAD SCREWS (3S) through holes #1 and #3. Roller end These holes must be here. Roller end GOLD 5/16" FLAT HEAD SCREW (12 used in this step) Finished edge Roller end www.sauder.com/services 409733 Page 9...
  • Page 10 Tighten Risk of damage or Arrow injury. HIDDEN CAMS must be completely Arrow Maximum tightened. HIDDEN 210 degrees CAMS that are not completely tightened may loosen, and parts may separate. To Minimum completely tighten: 190 degrees Page 10 409733 www.sauder.com/services...
  • Page 11 NOTE: Be sure the METAL PIN in the HUTCH SHELF inserts å into the hole in the HUTCH LEFT END. Angled edge S u r f a c Finished edge H I D D E N i t h www.sauder.com/services 409733 Page 11...
  • Page 12 HUTCH RIGHT END. Turn the HUTCH assembly over onto its front angled edge å and fasten the HUTCH RIGHT END (Y3) to the HUTCH BACK (CC). Tighten two HIDDEN CAMS. Angled edge Page 12 409733 www.sauder.com/services...
  • Page 13 BLACK 1-7/8" FLAT HEAD SCREW (6 used in this step) Be sure the head of this SCREW is fl at against the TOP. Finished edge www.sauder.com/services 409733 Page 13...
  • Page 14 Fasten the LEFT END (B2) to the TOP (D2). Tighten two å HIDDEN CAMS. Maximum Arrow 210 degrees Minimum 190 degrees i t h f a c S u r D E N H I D Roller end For support, place packing foam and magazines here. Page 14 409733 www.sauder.com/services...
  • Page 15 Fasten the MODESTY PANEL (F2) to the LEFT END (B2). å Tighten three HIDDEN CAMS. Maximum Arrow 210 degrees Minimum 190 degrees S u r f a c H I D D E N i t h Notch www.sauder.com/services 409733 Page 15...
  • Page 16 NOTICE: The orientation view has been changed from the last step with the RIGHT END (A2) here. The large hole must be here. i t h f a c S u r D E N H I D Page 16 409733 www.sauder.com/services...
  • Page 17 BLACK 1-7/8" FLAT HEAD SCREWS (2S). Minimum 190 degrees BLACK 1-7/8" FLAT HEAD SCREW (3 used for the MODESTY PANEL) i t h f a c S u r D E N H I D Finished edge www.sauder.com/services 409733 Page 17...
  • Page 18 Rome. This can be built NOTE: Adjustments to the ADJUSTABLE FOOT (34E) will å in a day. be made in Step 20 after your unit is standing upright. BLACK 9/16" LARGE HEAD SCREW (4 used in this step) Page 18 409733 www.sauder.com/services...
  • Page 19 Fasten the PENCIL DRAWER BACK (D121) to the Fasten the DRAWER BRACE (M64) to the PENCIL PENCIL DRAWER SIDES (D83 and D84) and DRAWER DRAWER FRONT (I). Tighten one HIDDEN CAM. BRACE (M64). Use five BLACK 1-9/16" FLAT HEAD SCREWS (30S). www.sauder.com/services 409733 Page 19...
  • Page 20 Fasten the DRAWER BACK (D77) to the DRAWER SIDES (D30 and D31). Use four BLACK 1-9/16" FLAT å HEAD SCREWS (30S). NOTE: Be sure the DRAWER BOTTOM (D716) inserts into the groove of the DRAWER BACK (D77). å Repeat this step for the remaining drawer. å Page 20 409733 www.sauder.com/services...
  • Page 21 Repeat this step for the other drawers. å Screw head - turn CAM to Roller end line up holes in SLIDES with holes in DRAWER SIDES. (6 used) Roller end GOLD 5/16" FLAT HEAD SCREW (12 used in this step) www.sauder.com/services 409733 Page 21...
  • Page 22 Fasten the KNOB (24K) to the PENCIL DRAWER FRONT (I) as shown in the lower diagram. å Use a BLACK 7/8" MACHINE SCREW (37S). SILVER 5/8" MACHINE SCREW (2 used for the PULL) BLACK 7/8" MACHINE SCREW (1 used for the KNOB) Page 22 409733 www.sauder.com/services...
  • Page 23 BLACK 1-1/8" PAN HEAD SCREW (4 used for the DRAWER FRONT) SILVER 5/8" MACHINE SCREW (4 used for the PULLS) 1. Fasten the PULLS (7K) These edges before you attach the should be even. DRAWER FRONT (N). www.sauder.com/services 409733 Page 23...
  • Page 24 Push a GROMMET CAP (1P) and GROMMET (10P) into the large hole in the TOP (D2). å 20 lbs. 50 lbs. 5 lbs. 15 lbs. 30 lbs. (3 used) With your No. 2 Phillips Screwdriver, turn the ADJUSTABLE FOOT To cover HIDDEN CAMS downward until it touches the fl oor. Floor Page 24 409733 www.sauder.com/services...
  • Page 25 #4. The higher the screw in the oblong hole, the higher your drawer front will be. The lower the screw, the lower the drawer front. www.sauder.com/services 409733 Page 25...
  • Page 26 EXTRÉMITÉ DROITE ............. 1 40CA ÉLÉMENT DROITE..............3 pour future référence. EXTRÉMITÉ GAUCHE ............1 40CB ÉLÉMENT GAUCHE .............3 Pour contacter Sauder MONTANT..................1 40CC TIROIR DROIT ................3 en ce qui concerne cet DESSUS ..................1 40CD TIROIR GAUCHE ..............3 élément, faire référence...
  • Page 27 Fixer le VOILE DE FOND (F2) à l’EXTRÉMITÉ DROITE (A2). Serrer trois EXCENTRIQUES ESCAMOTABLES. Utilisation de la FIXATION TWIST-LOCK® SAUDER Fixer le DESSOUS (E3) à l’EXTRÉMITÉ DROITE (A2). Serrer deux 1. Insérer l'extrémité fi letée de la FIXATION dans le trou de la pièce attenante.
  • Page 28 REMARQUE : Prière de lire les informations importantes sur la sécurité Répéter cette étape pour les autres tiroirs. fi gurant sur les pages arrière du manuel d’instructions. Ceci complète l'assemblage. Nettoyer à l’ a ide d’une encaustique pour meubles ou d’un chiff on humide. Essuyer. Page 28 409733 www.sauder.com/services...
  • Page 29 40CB GABINETE IZQUIERDO .............3 EXTREMO IZQUIERDO ..............1 pour future référence. 40CC CAJÓN DERECHO ..............3 PARAL ......................1 Pour contacter Sauder 40CD CAJÓN IZQUIERDO .............3 PANEL SUPERIOR ................1 en ce qui concerne cet EXCÉNTRICO DE CORREDERA ........6 LADO DERECHO DE CAJÓN GRANDE ......1 élément, faire référence...
  • Page 30 PASO 2 PASO 7 Gire trece BIELAS DE EXCÉNTRICO (8F) en las Cómo utilizar el SUJETADOR TWIST-LOCK® SAUDER PATAS (G y H) y la CARA DE CAJÓN PARA LÁPICES (I). 1. Inserte el extremo con cabilla del SUJETADOR dentro del agujero de la parte adjunta.
  • Page 31 Fije el EXTREMO DERECHO (A2) al PANEL SUPERIOR (D2). Apriete dos EXCÉNTRICOS ESCONDIDOS. Fije el VELO DE FONDO (F2) al EXTREMO DERECHO (A2). Apriete tres EXCÉNTRICOS ESCONDIDOS. Fije el FONDO (E3) al EXTREMO DERECHO (A2). Apriete dos EXCÉNTRICOS ESCONDIDOS. www.sauder.com/services 409733 Page 31...
  • Page 32 NOTA: Por favor, lea las páginas de atrás del folleto de instrucciones en cuanto a importante información de seguridad. Esto completa el ensamblaje. Limpie con su pulimento para muebles preferido o un paño húmedo. Seque con un paño. Page 32 409733 www.sauder.com/services...
  • Page 33 à Les téléviseurs peuvent être particulièrement un téléviseur. cet eff et. lourds. De plus, le poids et l’emplacement du tube image ont tendance à rendre les téléviseurs instables et enclins à tomber vers l’ a vant. www.sauder.com/services 409733 Page 33...
  • Page 34 Además, el peso y la ubicación del tubo de imagen tienden a causar la inestabilidad de televisores y propensa a volcarse hacia adelante. Page 34 409733 www.sauder.com/services...
  • Page 35 à compter de la date d'achat la première fois et qui sont signalés à Sauder dans les limites de couverture de la contre tout défaut de matériaux ou de fabrication des composantes de mobilier Sauder.
  • Page 36 Dear Valued Customer: So, how did it go? Thanks so much for choosing Sauder® furniture. I hope the Set a world record for speed? purchase and assembly process was a positive experience Feeling good about yourself? and you feel good about the furniture you just built. If you Nice.
