Introduction
Scratch-A-Way7 is the comprehensive system to remove surface scratches and corrosion from glass surfaces. The Scratch-A-Way7 system is convenient
and easy-to-use since you only work with one polishing disc.
The Scratch-A-Way7 system removes scratches from planar or convex as well as concave panes. The specially developed head adapts to the surface being
worked on.
This way you don=t have to disassemble glass panes which are already installed and you can work on them on site, which means:
reduced labour costs due to on-site repairing
!
no costly removal and re-installation of the glass pane
!
no additional transportation costs
!
Scratch-A-Way7 is a world-wide patented system, consisting of two versions of equipment and consumables. The two versions of equipment are:
A pneumatic system Art. No. 94001
An electrical system Art. No. 965020 (220 V) / Art. No. 965025 (110 V)
Technical specification
Connecting data
-Scratch-A-way air tool : Uniform connection G 1/4".
-Air hose : Uniform connection G 1/4".
-Compressor : Ideal working pressure 6-7 bar (75-90 p.s.i.).
Technical specifications
Air consumption : 280 l/min. (74 US.Gal. p/min.)
Speed : 11,000 rpm
Weight : 750 g
Preparing for operation
Connect the air tool directly to your compressor with the air hose.
Fasten the fine polish disc to the basic head.
Attention: this should happen in a centered manner.
Put the plug of the machine into a socket. The mains voltage has to comply with the power indicated on the type plate!
Mount the disc bearer on the machine, using the supplied blocking pin. By blocking the driving mechanism with the blocking
pin, the disc bearer can be screwed in.
Attention! Remove the blocking pin before using the machine.
Switch the machine to the highest level (Level 6)
Preparation
Before we start with the Scratch-A-Way7 scratch removal we must first clean the glass thoroughly.
(A suitable shammy included.)
If possible, we mark the scratch(es) at the back of the glass with the marker supplied.
