8/ TECHNICAL SPECIFICATIONS
Equipment type
Energy source
Qn (at 50.7 psi) (kW)
Operating pressure (bar)
Adjustable power (from 21.7 psi to
50.7 psi) (kW)
Flow rate (kg/hr)
Air consumption (m³/hr)
Weight (kg)
Safety device
Excess flow
Suitable accessories
Noise level (dBA)
9/ ACCESSORIES
FITTING THE DEFLECTOR – Item. 35088
FITTING THE AIR CLIP – Item .35198
35270b-EN-FR-NL-ES-PT
RAFALE
Propane / I3P
150000 BTU
21.7 to 50.7 psi
From 82000 to 150000 BTU
From 3.74 to 7.05 lb/h
From 36.62 cu yd/ph to 58.85
cu yd/ph (approx)
2.64 lb
"Dead man's handle" with
protection
Excess flow safety device on
regulator gauge
Thermal protection
"Air" clip
82-83
To prevent too much heat being transferred towards
•
the operator's hand.
Using the hex spanner supplied with the equipment, fit
•
the deflector as indicated above.
Prevents working clothes from obstructing the venturi
•
during heat-shrink operations.
Withdraw the protective O-ring at the rear of the
•
equipment and clip the air clip in this location.
RAFALE +
Propane / I3P
220000 BTU
21.7 to 50.7 psi
From 126000 to 220000 BTU
From 5.73 to 10.58 lb/h
From 62.78 cu yd/ph to 94.17
cu yd/ph (approx)
2.64 lb
"Dead man's handle" with
protection
Excess flow safety device on
regulator gauge
Thermal protection (original)
"Air" clip
85-88
6
