RD-ID45 Exploded view & Spare Parts List
Parts
Description
No.
1
Pan head screw M5 × 25
(cross tooth)
2
Drill chuck
3
output shaft
4
Woodruff key 3×10
5
Impact spring
6
6201 Bearing
7
φ 12 Retaining ring for shaft
8
big gear wheel
9
φ 9 Retaining ring for shaft
10
Copper sleeve φ12×φ 8×10
11
Impact block
12
Impact push button
13
Impact iron sheet
14
608 bearing (rubber cover)
15
rotor
16
Brush box 5.5×9
17
Carbon brush cover
Qty
Parts
No.
1
18
Carbon brush 5.5×9
19
607 Bearing (iron cover)
1
20
stator
1
21
Right casing
1
22
Cross pan head tapping screw
1
ST4 × 16
23
1
Forward and reverse push
buttons
1
24
Outgoing line
1
25
switch
1
26
Cross pan head tapping screw
1
ST4 × 14
1
27
Cable pressing plate
1
28
Left casing
1
29
Jacket (with key)
1
30
Cable line
1
31
Ruler
2
32
Auxiliary handle assembly
2
33
Chuck key
Description
73
Qty
2
1
1
1
11
1
2
1
2
1
1
1
1
1
1
1
