- Page 1 Owner's Manual Mode d’emploi HDZ-653 HDZ-65C SHEN ZHEN QICAI TECHNOLOGY CO., LTD. Building 197, Tongyufu Industrial Zone, Weizai New Village, Kukeng Community, Printed in China guanlan street, Longhua District, Shenzhen City, China 68-44781Z26-A (Y-A3)
- Page 2 CONTENTS / CONTENU / HDZ-653 HDZ-65C ×2 ×2 ×2 ×2 Woofer ×8 ×8 4 × 30 mm 4 × 30 mm ×8 ×8 ×2 Midrange ×2 Speaker ×8 3 × 30 mm ×2 ×2 Tweeter ×2 ×2 ×2 ×2 ×8 ×4 3 ×...
- Page 3 EXTERNAL DIMENSIONS / DIMENSIONS EXTERNES / ■ ■ Woofer (HDZ-653/HDZ-65C) Woofer (HDZ-653/HDZ-65C) (mm) 160.4 (6 3/8”) 4× 4.5 (3/16”) 3×90° (1/8”) 66.9 24.3 (2 3/4”) (9/32”) (1/8”) (31/32”) ■ ■ Midrange Speaker (HDZ-653) Haut-parleur médium (HDZ-653) (mm) 87.4 (3 1/2”) 4×...
- Page 4 ■ ■ Tweeter (HDZ-653/HDZ-65C) Tweeter (HDZ-653/HDZ-65C) 7.5 (5/16”) 7.6 (5/16”) (3/8”) 30.3 16.2 (1/4”) (1 1/4”) (21/32”) ■ ■ Network (HDZ-653) Filtre (HDZ-653) 50.2 (2”) 183 (7 1/4”) ■ ■ Network (HDZ-65C) Filtre (HDZ-65C) 40 (1 5/8”) 134.9 (5 3/8”)
- Page 5 WIRING CONNECTION / CONNEXIONS DE CABLAGE / ■ HDZ-653 Tweeter Network Input Midrange Speaker Woofer Output (R) Output (L) Woofer Midrange Speaker Input Network Tweeter ■ HDZ-65C Tweeter Network Input Woofer Output (R) Output (L) Woofer Input Network Tweeter...
- Page 6 INSTALLATION / INSTALLATION / ■ ■ Woofer (HDZ-653/HDZ-65C) Woofer (HDZ-653/HDZ-65C) ■ ■ Midrange Speaker (HDZ-653) Haut-parleur médium (HDZ-653) ■ ■ Tweeter (HDZ-653/HDZ-65C) Tweeter (HDZ-653/HDZ-65C)
- Page 7 ■ ■ Network (HDZ-653) Filtre (HDZ-653) ■ ■ Network (HDZ-65C) Filtre (HDZ-65C)
- Page 8 SPECIFICATIONS / CARACTERISTIQUES / ■ SPECIFICATIONS HDZ-653 HDZ-65C Units Type Woofer 6-1/2”(16.5 cm) Carbon Cone 6-1/2”(16.5 cm) Carbon Cone Midrange Speaker 3-1/2”(8.9 cm) Carbon Cone Tweeter 1-1/4”(3.2 cm) Carbon Cone 1-1/4”(3.2 cm) Carbon Cone Maximum Peak Power 300 Watts in system 300 Watts in system Maximum RMS Power 100 Watts in system...
