8-Watt Wide-Angle Light Specs
Model
Dimensions
Material
Voltage Min-Max
Wattage
Lumens
Kelvin Temperature
Color Rendering Index (CRI)
Beam Angle Spread
Bulb Life
Cord Length
Installation
MOUNTING OPTIONS
• Choose the option that works best for your application.
– Flexible Light Stand (#84081 sold separately)
ƒ Thread the universal mount adapter to the included
thumb screw.
ƒ Position the legs of the flexible stand into desired
shape.
ƒ Slide the universal mount adapter onto the bottom of
the light until it clicks in place (Ex. 1).
– Light Stake (#84080 sold separately)
ƒ Thread the universal mount adapter onto the stake
using the washer to position the adapter in the desired
direction.
ƒ Adjust the angle of the light and tighten down the
thumb screw when in the desired position (Ex. 2).
– Universal mounts
ƒ The Universal Mount Adapter uses ¼" 20 threads
to allow for many other standard camera or phone
mounting options readily available to you (Ex. 3).
– No stand or stake
ƒ The light can be used without the universal mount
adapter by tucking them gently between rocks in the
pond or waterfall (Ex. 4).
2
8-Watt Wide-Angle Light
2.7"L x 3.8"W x 2.8"H
Die-Cast Metal
10.8V–15V
8W±10%
840 lm
3,000 K
70
90°
50,000 Hours
25'
Ex. 1
CONNECT LIGHT FIXTURES
• Aquascape pond and landscape white lights include
2-pin, quick-connect fittings to provide tool-free electrical
connections.
• Splitters and extension cables are available to install
multiple lights. See the recommended products section for
available extensions and splitters.
• Connect lights to quick-
connect splitters and
extensions (Ex. 5).
NOTE: Quick-connect
connections must be fully
tightened to prevent water
from entering. Dielectric
grease, available at most
home improvement stores,
can be used in all connections to further prevent water
infiltration.
• If desired, the Quick-Connect Photocell with Timer can
be installed at this time (see the recommended products
section for more information).
WARNING: Do not submerge quick-connect
fittings, as moisture entering the connections will
damage the lights.
NOTE: The light can also be wired directly in pre-existing
low-voltage lighting systems. Cut off the quick-connect
and use a UL listed connector rated for outdoor use.
NOTE: Light failure as a result of improper wiring is not
covered under warranty.
Ex. 2
TRANSFORMER SETUP
• Aquascape pond and landscape lights are designed to
operate on a 12-volt, outdoor-rated transformer.
WARNING: Aquascape pond and landscape lights
have a max voltage operating range between 10.8
and 15 volts. Operating the light outside of this
voltage range voids the product warranty and may
damage or shorten the life of the light.
☎
☎
US (866) 877-6637 |
Ex. 3
CAN (866) 766-3426 | aquascapeinc.com
Ex. 4
Ex. 5
