Installation
1 Installing the arm to the wall
plate
□
Place the hole on the bottom of the arm (A) align
the hole of wall plate (B).
□
Screw the set screw (C) into the wall plate(B) to
fixed the arm (A).
2 Attaching the cross bar to
the outlet box
□ Screw the mounting screws (CC) into the cross
bar (EE) so that the threads face out.
□ Mount the cross bar (EE) to the outlet box (not
included) using the outlet box screws (BB).
□ Make sure the threads of the mounting
screws (CC) are facing out when the cross
bar (EE) is attached to the outlet box.
5 HOMEDEPOT.COM/HOMEDECORATORS
Please contact 1-800-986-3460 for further assistance.
