Remove from below the vehicle any protective sealant from the points of contact between the shell and the tow bar; then paint the
uncovered parts with rust preventer. The holes for the tow bar's fixing are available.
1.
Disassemble the luggage compartment's inner cladding.
2.
Eliminate part of the protective paint that can be found on the luggage compartment's left side.
3.
From inside the luggage compartment make some holes in correspondence to the existing benchmarks "1" and "2"; widen
gradually with a bit of Ø 18 mm only the upper side (the holes on the spar's lower side are already made).
4.
From inside the luggage compartment place the sparers within holes "1" and "2", place components "D" and "E" and insert
screws.
5.
From underneath the vehicle place components "B" and "C" with reference to screws "1" and "2" ; fix interjecting the wide
washers in correspondence to point "2".
6.
Place tow beam "A" between components "B" and "C" with reference to holes "3" and "4"; insert screws and then fix.
7.
Tighten all bolts and nuts with a tightening torque as shown in the enclosed layout.
8.
Connect the wiring to the socket (usually given apart), following the car booklet's instructions "use and maintenance" as
shown in the enclosed wiring kit layout.
9.
Reassemble the luggage compartment's inner cladding.
•
Make sure that the tow bar is suitable for the vehicle before starting the installation. Verify also that the vehicle's towing
disposal quoted on the car registration is mentioned on the tow bar document. Otherwise ask for the appropriate office
(umbrarimorchi@umbrarimorchi.it) for explanations or updated documents.
•
For safety, all work involving tow bar installation must be undertaken by skilled technicians.
•
Damaged components must be replaced with manufacturer's spares parts by qualified staff.
•
It is forbidden to make any modification or structural repair to the tow bar.
•
The tow ball must be kept clean and lubricated. For added safety, his diameter (50 mm) must be checked at regular
intervals. If the tow ball measures less than 49 mm after selected readings across the diameter, the tow ball must be
replaced with a new one.
•
After 1000 km of towing, check torque settings for nuts and bolts, in accordance with the table.
FITTING INSTRUCTIONS
SAFETY INSTRUCTIONS
USE AND MAINTENANCE
28053 • 1.6 • 13/06/2023
