10. Rotary Volume/Scroll/Select control:
• Rotate: Adjust the volume
• Rotate in the menu or presets: Scroll through the available menu
options or preset locations
• Short press: Select a displayed radio station/frequency, menu or
preset option
• When alarm is sounding in standby, short press: activates
10-minute snooze.
11. Headphone jack
12. USB input
13. Aux in
14. Power input
15. Aerial input
Remote control
(Refer to 2 on page 2).
1.
Press to power on or enter standby.
2.
Press to mute the sound. Press again to resume sound, or press
+/- to resume sound.
3. Presets (20 DAB/20 FM)
In DAB+/FM mode:
• Short press: Preset recall.
• Long press: Preset store.
In Bluetooth mode: Long press to disconnect current device and
scan for new devices.
4.
Menu: Press to enter the menu options.
5.
Info: Press to cycle through different types of information available.
6. DAB+/FM radio: Press to enter DAB+ mode, press again to enter
FM mode.
7. Short press to enter Bluetooth mode. Long press to disconnect
from paired device.
8. Press to change audio source to CD.
9. Press to change audio source to AUX. Press again to change audio
source to USB.
10.
Equaliser: Press to cycle through EQ options.
11.
Loudness compensation increases the low and high
frequencies when listening at low volume.
12.
Press to cycle through display brightness settings: high, medium
and low.
13.
In CD/USB mode: press to stop playback. Press again to open/
close CD drawer.
14.
- In DAB mode: Move up the DAB station list.
- In FM mode: Move down the frquency band by 0.05 MHz.
- In Menu: Move up the menu options.
15.
Select/Play/Pause. When alarm sounds, press to snooze.
16.
Short press for next track/station, long press for fast forward/
search forward.
17. Short press for previous track/station, long press to rewind/
search back.
18.
- In Menu: Move down the menu options.
- In DAB mode: Move down the DAB station list.
- In FM mode: Move up the frequency band by 0.05 MHz.
19.
Repeat: In CD/USB mode: Cycle through repeat options: repeat
current track, repeat all tracks, repeat off.
20. Shuffle: In CD/USB mode: Shuffle songs on/off.
21. In CD mode: Press to program the playback order.
22. In CD mode: Press once to play the first 10 seconds of every
track on a CD. Press again for the current track to play in full.
23. Bass +/-: Press to adjust the bass.
24. Volume +/-: Press to adjust the volume.
25. Treble +/-: Press to adjust the treble.
26. Numeric keypad (0-9): Used for song/preset selection.
27. Alarm: Press to set up Alarm 1/2.
When in standby, press to switch on/off alarms.
28. Sleep timer: Press to cycle through sleep timer options.
Using your DAB+/FM hi-fi all-in-one
system
Connection
NOTE: Your all-in-one system has been supplied with a power adapter.
Please check and ensure that you connect the correct 3 pin or 2 pin part to
the power adapter that is appropriate for the country where the product
will be used.
Connect the aerial to the back of the all-in-one system to receive the best
possible radio reception and signal quality.
Connect the power adapter lead to the power input on the back of the
all-in-one system and plug the power adapter into the wall socket and
switch on. The all-in-one system will power on and display <SHARP
sharpconsumer.eu> and then go into standby.
NOTE: The processes described here use the controls on the main unit (unless
specified). For controls using the remote control, please refer to the 'Remote
control' section.
Initial set-up
Extend the aerial to ensure the maximum signal strength when you scan
for radio stations.
Short press to switch on your all-in-one system. It will begin an
automatic scan for DAB stations. A progress bar will show the progress of
the scan and the number of stations found.
When the scan is complete your all-in-one system will select the first
available station and begin to play. By default, stations are listed
numerically and then alphabetically.
NOTE: The DAB radio station list is stored in the memory; the next time the
all-in-one system is switched on, the station search does not take place.
Short press or to scroll through the available stations. To select
the station displayed, short press
your all-in-one system tunes to your selected station.
Time and date
Time and date will be synchronised automatically to that broadcast by
the DAB service in 24-hour format.
To set the time and date manually, turn on the radio. Long press
enter the menu options.
to select <System> / <Time> / <Set Time/Date>. <Set
Use
time> is displayed and the hour digits will flash; use
hours and minutes. <Set date> is displayed and the day will flash; use
to set day, month and year. <Time Saved> is shown once the
year is confirmed and you will return to the <Set Time/Date> menu.
Use to change the clock/date format and auto update settings.
Long press to exit the menu.
Change the mode
Short press to change between <DAB+>, <FM>, <Bluetooth>,
<CD>, <USB>, and <Aux in>. modes. The display screen will confirm
the mode.
EN
. There will be a short delay whilst
to set
to
