GB
• Do not operate the product's buttons with electrically conductive objects!
• Do not operate the product at, on or in the vicinity of open flames (e.g. candles)!
• Do not bend using force!
• To avoid damage, do not bend or knot cables over sharp edges or corners!
• Note the cable length including power supply unit (total length: approx. 1.5m)
• Do not connect more than 7 Add On elements (type: EML262-RV1) to one controller (Type: EML262-S).
SCOPE OF DELIVERY
Check the delivery for completeness and perfect condition.
In the case of missing parts or damage:
• do not mount the unit!
• do not put the unit into operation!
• make a complaint to the supplier.
The deliver consists of:
• Product
• Mounting material (screws, drilling template, double-sided adhesive tape to fix the controller)
• Instructions
• Power supply unit (in starter set)
• Accessories (controller in starter set)
TECHNICAL DATA
• Output: 3,4W LED (per luminaire module)
• Illuminant: 56 SMD LEDs
• Luminous flux: 250lm
• Luminous efficacy: 73lm/W
• Colour temperature: 3000K + 6500K
• Colour rendering index (Ra/CRI): ≥ 80
• Energy efficiency class: A
• LED service life: 25000h
• Beam angle: 124°
• IP protection class: IP20
• Protection class: III (S8)
• Ambient temperature: 0°C - 35°C / max. 35°C
• Dimensions Luminaire W x H x D: 324 x 23 x 24mm
• Dimensions Controller W x H x D: 74 x 23 x 24mm
• Dimming mode: 10-100% infinitely variable
• Power supply unit:
• Input: 230V~; 50Hz
• Output: 24VAC, 1A, 24W
• Protection class: II (S9)
• Cable length: 100cm
INSTALLATION
Please refer to the drawings for the installation steps.
1. Remove the protective cap from the power input.
2. Remove the protective cap from the current output.
3. Remove the mounting bracket from the back of the lamp module and then attach it in the desired position
4. Fix the luminaire module to the mounting bracket.
5. Connect the controller to the power input of the first lamp module and fix it with the enclosed double-sided
adhesive tape.
6. Connect the plug connector of the power supply to that of the controller.
Note: If you want to connect several lamp modules together, you can use the enclosed drilling template.
