Summit SUP-07237S Mode D'emploi

Opel agila ii 09/2007 et ulterieure, suzuki splash ii 01/2008 et ulterieure, toyota yaris 03/2011 et ulterieure
Masquer les pouces
1
2
3
4
5
6
7
8

Publicité

Liens rapides

Télécharger ce manuel
TYPE A
3
SUP-07237S
OPEL Agila II
SUZUKI Splash II
TOYOTA Yaris
EN: Do not exceed maximum loading capacity given by roof bars. Do not exceed maxi-
mum loading capacity given by the vehicle manufacturer.
F: Ne pas dépasser la charge maximale des barres. Ne pas dépasser la charge maximale
IT: Non superare il carico massimo delle barre portatutto. Non superare il carico massimo
D: Maximal zugelassene Belastung des Lastenträgers nicht überschreiten. Maximal zu-
gelassene Dach-Belastung laut Fahrzeugherstellerangaben nicht überschreiten.
Mountnet Ltd, www.mountneyltd.com, Manufactured by Aurilis Group Italia
CITY CRASH TEST
ISO PAS 11154
??? KG
indiquée par le constructeur du véhicule.
indicato dal costruttore del veicolo.
MAX 75 KG
5
5
5
MAX 75 Kg
REV 05-2017
09/2007->
01/2008->
03/2011->

Publicité

loading

Manuels Connexes pour Summit SUP-07237S

Sommaire des Matières pour Summit SUP-07237S

  • Page 1 REV 05-2017 TYPE A CITY CRASH TEST MAX 75 KG ISO PAS 11154 SUP-07237S OPEL Agila II 09/2007-> SUZUKI Splash II 01/2008-> TOYOTA Yaris 03/2011-> MAX 75 Kg ??? KG EN: Do not exceed maximum loading capacity given by roof bars. Do not exceed maxi- mum loading capacity given by the vehicle manufacturer.
  • Page 2 M6X50 mm 162100001 6592.06 94013 1122501 1122502 1122503 1122504 237A 237B 81018...
  • Page 3 BRAND MODEL OPEL Agila 80 Cm 79 Cm SUZUKI Splash 80 Cm 79 Cm TOYOTA YARIS 82,5 Cm 80,5 Cm 10 Km 100 Km 500 Km 1000 Km CHECK! CHECK! CHECK! CHECK!
  • Page 4 1120601 1120602 244CD 244CD 1120603 1120604 238A 238B Max 3...
  • Page 5 MODEL Hyundai i20 29,5 Cm Opel Agila 17 Cm Suzuki Splash 17 Cm Yaris 99->05 37 Cm Yaris 06->11 36 Cm Yaris 11-> 39 Cm EN: Tighten alternately FR: Serrer alternativement chaque côtè IT: Serrare in modo alternato ES: Alternare il serraggio delle viti DE: Die Schrauben abwechselnd anziehen Lock ! CENT...
  • Page 6 MODEL Hyundai i20 59,5 Cm Opel Agila 70 Cm Suzuki Splash 70 Cm Yaris 99->05 69 Cm Yaris 06->11 69,5 Cm Yaris 11-> 69 Cm EN: Tighten alternately FR: Serrer alternativement chaque côtè IT: Serrare in modo alternato ES: Alternare il serraggio delle viti DE: Die Schrauben abwechselnd anziehen Lock ! CENT...
  • Page 7 EN: Unistall FR: Démontage IT: Smontaggio DE: Demontage CENT...
  • Page 8 Roof accessories can cause noise or turbulence during use. Do not fix the accessory to other brand’s fixing systems. Never exceed the speed limit indicated on the first page of the manual. If you have any doubts about fixing or use please contact your nearest branch of the distributor, SUMMIT.
