STRIDER ESSENTIAL SERIES
ST65F-ES230
Power for everything you need
High efficiency with 80 PLUS certification
24/7 continuous power output with 40℃ operating temperature
Class-leading single +12V rail
Active PFC Circuitry
PCI-E 8pin and PCI-E 6pin connector support
Silent running 120mm fan with 18dBA
Publicité
Manuels Connexes pour SilverStone STRIDER ESSENTIAL Serie
Sommaire des Matières pour SilverStone STRIDER ESSENTIAL Serie
- Page 1 STRIDER ESSENTIAL SERIES ST65F-ES230 Power for everything you need High efficiency with 80 PLUS certification 24/7 continuous power output with 40℃ operating temperature Class-leading single +12V rail Active PFC Circuitry PCI-E 8pin and PCI-E 6pin connector support Silent running 120mm fan with 18dBA...
- Page 2 SPECIFICATION SilverStone Strider Essential ST65F-ES230 ATX12V Switching Power Supply With Active PFC PS/2 1. INPUT: 1.1 VOLTAGE MINIMUM NOMINAL MAXIMUM UNITS 200-240 Vrms 1.2 FREQUENCY 47Hz ~ 63Hz 1.3 CURRENT 5.0A max. 1.4 INRUSH CURRENT Power no damage at AC input 230Vac and 25 C cold start.
- Page 3 1.6 LEAKAGE CURRENT 3.5mA max. 1.7 POWER FACTOR PF > 0.95 at 230Vac input and full load 1.8 ErP REQUIREMENT Meet ErP 2010 requirement (Standard) Meet ErP 2013 requirement(Optional) 2. OUTPUT: Voltage +3.3V +12V -12V +5Vsb ＊①Max load 20.0A 20.0A 50.0A 0.3A 2.5A...
- Page 4 2.2 HOLD-UP TIME 10msec (minimum) at 80% of full load at 230Vac input. 2.3 POWER GOOD DELAY 100-500 msec. 2.4 POWER FAIL DELAY 1 msec. 2.5 TURN-ON DELAY TIME 2000 msec max.At Nominal Line Full Load. 2.6 TRANSIENT OVERSHOOT DC output transient step sizes as below table: Output voltage +3.3V +12V...
- Page 5 3.2 SHORT PROTECTION All output to GND. 3.3 OVER POWER PROTECTION Foldback at 110%~150% over peak load 4. ENVIRONMENT: 4.1 OPERATING TEMP 0 C to +40 C 4.2 STORAGE TEMP -20 C to +70 C 4.3 OPERATING HUMIDITY 20% to 90%,non-condensing 5% to 95%, non-condensing 4.4 STORAGE HUMIDITY 4.5 OPERATING ALTITUDE...
- Page 6 Power supply connector overuse definition A single PCIe 8pin cable and connector’s maximum current rating is 12.5A, which is 150W (+12V x 12.5A). So SilverStone’s warranty will not cover damages or malfunction resulting from the use of a graphics card or expansion card with a single PCIe 8pin connector that exceeds standard 225W total power draw (150W from PCIe 8pin connector + 75W from PCIe motherboard slot).
- Page 7 La corrente massima del connettore a 24 pin per scheda madre per i suoi due pin di metallo a +12 V è di 5 A ciascuno, per un totale di 120 W (+12 V x 5 A x 2). Assicurarsi che i dispositivi a +12 V collegati alla scheda madre funzionino con questi limiti. La garanzia di SilverStone non copre danni o malfunzionamenti derivanti da uso eccessivo di questi connettori e dei relativi cavi.
- Page 8 전원 공급 커넥터 과용 정의 단일한 PCIe 8핀 케이블 및 커넥터의 최대 전류 정격은 12.5A로서 전력으로 환산하면 150W(+12V x 12.5A)입니다. SilverStone의 보증에서는 표준 225W의 총 소비 전력 (PCIe 8핀 커넥터의 150W와 PCIe 메인보드 슬롯의 75W의 합)을 초과하는 단일 PCIe 8핀 커넥터 탑재 그래픽...
- Page 9 กรุ ณ าให้ แ น่ ใ จว่ า อุ ป กรณ์ ท ี ่ ใ ช้ ง านมี ก ารใช้ พ ลั ง งานไม่ เ กิ น กว่ า ขี ด จำกั ด ที ่ ร องรั บ ดั ง นั...
- Page 10 Manufacturer: SilverStone Technology Co., Ltd Address: 12F No. 168 Jiankang Rd., Zhonghe Dist., New Taipei City 23585 Taiwan R.O.C Please refer to SilverStone website for latest specifications updates.
- Page 12 NO. G11235910...
