U P
®
ASME A112.18.1 / CSA B125.1
Models/Modelos/Modèles
T5722 Series/Series/Seria
Write purchased model number here.
Escriba aquí el número del modelo comprado.
Inscrivez le numéro de modèle ici.
You may need/Usted puede necesitar/Articles dont vous pouvez avoir besoin:
1/8" (3.17mm)
For easy installation of your Delta
faucet you will need:
• To READ ALL the instructions completely
before beginning.
• To READ ALL warnings, care, and maintenance
information.
• To complete the deck and valve rough-in prior to
installing this trim kit.
Para instalación fácil de su llave Delta
usted necesitará:
• LEER TODAS las instrucciones completamente
antes de empezar.
• LEER TODOS los avisos, cuidados, e
información de mantenimiento.
• Para completar el borde y la instalación de vál-
vulas dentro de las paredes previa a la
instalación de la llave y sus accesorios.
Pour installer votre robinet Delta
facilement, vous devez:
• LIRE TOUTES les instructions avant de déb-
uter;
• LIRE TOUS les avertissements ainsi que toutes
les instructions de nettoyage et d'entretien;
• Installez le corps du robinet et terminez le
pourtour du bain avant de poser les accessories
de finition.
62091
C
®
TWO HANDLE GARDEN ROMAN TUB TRIM
DE DOS MANIJAS PARA LA BAÑERA ROMANA
ESTILO JARDÍN
ROBINET DEUX MANETTES POUR BAIGNOIRE
ROMAINE DE JARDIN
T E FlO N
?
62091
1
3/32" (2.38mm)
1/8" (3.17mm)
3/32"
(2.38mm)
6/25/09
Rev. A
