112. 4 xxx ~ 112.6xxx Stack frame Aluminium
PRODUCT MANUAL
DE Produkthandbuch
FR
Manuel de produit
NL Producthandleiding
TÜV and DGUV (former BGV-C1) certified
Number of registration: 17_060-3_Cert
CONTENTS
CONTENTS
Product manual
Mounting regulations
Guarantee terms and conditions
Mounting regulations
Important safety instructions
Guarantee terms and conditions
Mounting instructions
Declaration of conformity
User manual
Mounting instructions
Specification sheets
User manual
Instructions reset controlbox
Specification sheet
Contact details
original language English
1
2
3
2
4
3
5
4
7
5
12
11
14
15
16
Publicité
Manuels Connexes pour Smart Metals 112.4 Serie
Sommaire des Matières pour Smart Metals 112.4 Serie
- Page 1 112. 4 xxx ~ 112.6xxx Stack frame Aluminium TÜV and DGUV (former BGV-C1) certified Number of registration: 17_060-3_Cert PRODUCT MANUAL original language English DE Produkthandbuch CONTENTS CONTENTS Manuel de produit Product manual Mounting regulations NL Producthandleiding Guarantee terms and conditions Mounting regulations Important safety instructions Guarantee terms and conditions...
- Page 2 MOUNTING REGULATIONS Page 2 112. 4 xxx ~ 112.6xxx Stack frame Aluminium Mounting regulations Montagevorschriften WARNING WARNUNG A correct mounting is extremely important and this is not the responsibility of Eine korrekte Montage ist von größter Bedeutung, und SmartMetals Mounting SmartMetals Mounting Solutions.
- Page 3 GUARANTEE TERMS AND CONDITIONS Page 3 112. 4 xxx ~ 112.6xxx Stack frame Aluminium Guarantee terms and conditions Garantiebedingungen 1. SmartMetals Mounting Solutions guarantees that a product that SmartMetals 1. SmartMetals Mounting Solutions garantiert, dass ein Produkt, bei dem has determined to be defective as a result of deficient manufacture or material SmartMetals Defekte infolge von Fabrikations- oder Materialfehlern feststellt, this will be repaired or –...
- Page 4 IMPORTANT SAFETY INSTRUCTIONS Page 4 112. 4 xxx ~ 112.6xxx Stack frame Aluminium The maximum admissible load of the Stack frame Die maximal zulässige Belastung des varies dependant on the way of use. Stapelrahmens hängt von der Nutzungsart ab. We strongly refer you to check your specific way Wir verweisen Sie stark darauf, Ihre spezifische of mounting and the corresponding maximum Montageart und die entsprechende maximale...
- Page 5 MOUNTING INSTRUCTIONS Page 5 112. 4 xxx ~ 112.6xxx Stack frame Aluminium projector speci c...
- Page 6 MOUNTING INSTRUCTIONS Page 6 112. 4 xxx ~ 112.6xxx Stack frame Aluminium max 3.5° max 3.5° max 7° max 5° max 5° max 2.5°...
- Page 7 USER MANUAL Page 7 112. 4 xxx ~ 112.6xxx Stack frame Aluminium With 4x truss clamps (ref. 003.1128) With 2x truss clamps (ref. 003.1128) and 2x clamp (ref. 112.1017)
- Page 8 USER MANUAL Page 8 112. 4 xxx ~ 112.6xxx Stack frame Aluminium Truss clamps positions as indicated below Max. load 280 kg with safety, Max. load 100 kg with safety, else max. load 140 kg else max. load 50 kg Max.
- Page 9 USER MANUAL Page 9 112. 4 xxx ~ 112.6xxx Stack frame Aluminium With 1x rental mount (ref. 002. 4 600) 002.4600 Max. load 200 kg with safety, else max. load 100 kg Stacking several frames...
- Page 10 USER MANUAL Page 10 112. 4 xxx ~ 112.6xxx Stack frame Aluminium Max. 3 stackframes Short throw use...
- Page 11 USER MANUAL Page 11 112. 4 xxx ~ 112.6xxx Stack frame Aluminium IMPORTANT NOTE: The loads depend on the upper attachment. The maximum loads stated on pages 9 and 10 must be observed! Transport...
- Page 12 SPECIFICATION SHEET Page 12 112. 4 xxx ~ 112.6xxx Stack frame Aluminium 112.4160 Net weight 11.90 kg Gross weight Max. load 100.00 kg M6 (4x) 287.5 Max. stacked weight to top frame is 275 Kg (606 lbs) SmartMetals Product: Stack frame Alu. (Small 160) Max.500x560x160 (WxLxH) Mounting Solutions BV 112.4200 Pascalweg 13...
