152.1000-77~101 Floor lift for Interactive Whiteboard 77 – 101 inch
PRODUCT MANUAL
DE Produkthandbuch
FR
Manuel de produit
NL Producthandleiding
SmartMetals Mounting Solutions B.V. • Vlietskade 8016 • 4241 WS ARKEL• The Netherlands
T +31 (0)88 70 60 100 • E info@smartmetals.nl • W www.smartmetals.nl
CONTENTS
CONTENTS
Product manual
Important safety information
Mounting regulations
Mounting regulations
Guarantee terms and conditions
Guarantee terms and conditions
Declaration of conformity
Declaration of conformity
Mounting instructions
Mounting instructions
Instructions reset controlbox
User manual
Specification sheet
Instructions reset controlbox
Specification sheet
Wiring diagram
Contact details
original language English
1
2
6
2
7
3
8
4
9
5
14
11
15
14
15
18
16

Publicité

Table des Matières
loading

Sommaire des Matières pour Smart Metals 152.1000-77

  • Page 1 152.1000-77~101 Floor lift for Interactive Whiteboard 77 – 101 inch PRODUCT MANUAL original language English DE Produkthandbuch CONTENTS CONTENTS Manuel de produit Product manual Important safety information NL Producthandleiding Mounting regulations Mounting regulations Guarantee terms and conditions Guarantee terms and conditions...
  • Page 2: Electrical Safety

    IMPORTANT SAFETY INFORMATION - GB Page 2 152.1000-77~101 Floor lift for Interactive Whiteboard 77 – 101 inch Important safety information for both installer and user Installer: Before starting the installation read the safety instructions, the mounting regulations and rest of this product manual carefully.
  • Page 3 WICHTIGE SICHERHEITSHINWEISE - DE Page 3 152.1000-77~101 Floor lift for Interactive Whiteboard 77 – 101 inch Wichtige Sicherheitsinformationen für Installateur und Benutzer Installateur: Lesen Sie vor Beginn der Installation die Sicherheitshinweise, die Montagevorschriften und den Rest dieses Produkthandbuchs sorgfältig durch. Wenn Sie nicht alle Anweisungen lesen, verstehen und nicht befolgen, kann dies zu schweren Verletzungen, Geräteschäden oder zum Erlöschen der Werksgarantie führen! Es liegt in der...
  • Page 4 INFORMATIONS DE SÉCURITÉ IMPORTANTES - FR Page 4 152.1000-77~101 Floor lift for Interactive Whiteboard 77 – 101 inch Informations de sécurité importantes pour l’installateur et l’utilisateur l’Installateur: Avant de commencer l’installation, lisez attentivement les consignes de sécurité, les réglementations de montage et le reste de ce manuel du produit.
  • Page 5 BELANGRIJKE VEILIGHEIDSINFORMATIE - NL Page 5 152.1000-77~101 Floor lift for Interactive Whiteboard 77 – 101 inch Belangrijke veiligheidsinformatie voor zowel installateur als gebruiker Installateur: Lees de veiligheidsinstructies, de montagevoorschriften en de rest van deze producthandleiding zorgvuldig door voordat u met de installatie begint. Als u niet alle instructies leest, volledig begrijpt en niet opvolgt, kan...
  • Page 6: Mounting Regulations

    MOUNTING REGULATIONS Page 6 152.1000-77~101 Floor lift for Interactive Whiteboard 77 – 101 inch Mounting regulations Montagevorschriften WARNING WARNUNG A correct mounting is extremely important and this is not the responsibility of Eine korrekte Montage ist von größter Bedeutung, und SmartMetals Mounting SmartMetals Mounting Solutions.
  • Page 7: Garantiebedingungen

    GUARANTEE TERMS AND CONDITIONS Page 7 152.1000-77~101 Floor lift for Interactive Whiteboard 77 – 101 inch Guarantee terms and conditions Garantiebedingungen 1. SmartMetals Mounting Solutions guarantees that a product that SmartMetals 1. SmartMetals Mounting Solutions garantiert, dass ein Produkt, bei dem...
  • Page 8: Declaration Of Conformity

    DECLARATION OF CONFORMITY Page 8 152.1000-77~101 Floor lift for Interactive Whiteboard 77 – 101 inch GB Declaration of conformity DE Konformitätserklärung Manufacturer: Hersteller: SmartMetals Mounting Solutions BV SmartMetals Mounting Solutions BV Vlietskade 8016 Vlietskade 8016 4241 WS ARKEL 4241 WS ARKEL...
  • Page 9: Mounting Instructions

    MOUNTING INSTRUCTIONS Page 9 152.1000-77~101 Floor lift for Interactive Whiteboard 77 – 101 inch 4|2x 9|4x 152.1000-77~101 10|M8 Ø20|16x 11|M8|4x 12|M6x12|1x 13|M8x16|8x 14|M8x25|4x 15|V8 8ST M8|8x 4|2x 152.1000-77~101 9|4x & 152.1045 10|M8 Ø20|18x 11|M8|4x 12|M6x12|1x 13|M8x16|8x 17|M8x20|2x 14|M8x25|4x 15|V8 8ST M8|8x SmartMetals Mounting Solutions B.V.
  • Page 10 MOUNTING INSTRUCTIONS Page 10 152.1000-77~101 Floor lift for Interactive Whiteboard 77 – 101 inch L = X L = X 16 2x 14 2x 17 2x 19 2x 13 2x L=75+L1+L2+L3-L4 SmartMetals Mounting Solutions B.V. • Vlietskade 8016 • 4241 WS ARKEL• The Netherlands...
  • Page 11 MOUNTING INSTRUCTIONS Page 11 152.1000-77~101 Floor lift for Interactive Whiteboard 77 – 101 inch 18 4x L = X L = X 17 2x 14 8x 14 2x 15 4x 16 2x Max. 25 kg Max. 55 lbs SmartMetals Mounting Solutions B.V. • Vlietskade 8016 • 4241 WS ARKEL• The Netherlands...
  • Page 12 MOUNTING INSTRUCTIONS Page 12 152.1000-77~101 Floor lift for Interactive Whiteboard 77 – 101 inch 14 2x 17 2x 230V AC, 50Hz 16 2x 16 2x 14 2x 17 2x max 5 max 5 Max. 80 kg max 5 Max. 176 lbs max 5 SmartMetals Mounting Solutions B.V.
  • Page 13 MOUNTING INSTRUCTIONS Page 13 152.1000-77~101 Floor lift for Interactive Whiteboard 77 – 101 inch Max. 80 kg Max. 176 lbs max 5 max 5 max 5 max 5 SmartMetals Mounting Solutions B.V. • Vlietskade 8016 • 4241 WS ARKEL• The Netherlands...
  • Page 14: Instructions Reset Controlbox

    INSTRUCTIONS RESET CONTROLBOX Page 14 152.1000-77~101 Floor lift for Interactive Whiteboard 77 – 101 inch - Check the connection from the remote - Check the connection from to the controlbox the power plug to the controlbox - Überprüfen Sie die Verbindung von der - Überprüfen Sie die Verbindung vom...
  • Page 15: Specification Sheet

    SPECIFICATION SHEET Page 15 152.1000-77~101 Floor lift for Interactive Whiteboard 77 – 101 inch 152.1000-77 Net weight 59 kg Gross weight 69 kg 42.5 Max. load 80 kg 1600 - 1899 1600 DETAIL B SCALE 0.100 lens centre 42.5 185 - 600...
  • Page 16 SPECIFICATION SHEET Page 16 152.1000-77~101 Floor lift for Interactive Whiteboard 77 – 101 inch 152.1000-87 Net weight 60 kg Gross weight 70 kg Max. load 80 kg 42.5 1900 - 2099 1900 DETAIL B SCALE 0.100 lens centre 42.5 185 - 600...
  • Page 17 SPECIFICATION SHEET Page 17 152.1000-77~101 Floor lift for Interactive Whiteboard 77 – 101 inch 152.1000-101 Net weight 61 kg Gross weight 71 kg Max. load 80 kg 42.5 2100 - 2299 2100 DETAIL B SCALE 0.100 lens centre 42.5 185 - 600...
  • Page 18: Wiring Diagram

    WIRING DIAGRAM Page 18 152.1000-77~101 Floor lift for Interactive Whiteboard 77 – 101 inch RJ45 8 PINS CONTROL CABLE Grey Orange White Blue Green Yellow Violet Cable wire color Function RJ45 8 Pin plug no. Blue + Green Reference 1 Up...
