WARNING - SAFETY RULES
GENERAL INSTRUCTIONS
Read and understand the following safety recommendations before using or servicing the unit.
Any modification or servicing that is not specified in the instruction manual must not be undertaken.
The manufacturer is not liable for any injury or damage due to a non-compliance with the instructions featured this manual.
In the event of problems or doubts, please consult a qualified person to handle the installation properly.
ENVIRONMENT
This equipment should only be used for welding operations performed within the limits indicated on the information panel and/or in this manual. These
safety guidelines must be observed. The manufacturer cannot be held responsible in the event of improper or dangerous use.
The machine must be set up somewhere free from dust, acid, flammable gases or any other corrosive substances. This also applies to the machine's
storage. Ensure good air circulation when in use.
Temperature range:
Use between -10 and +40°C (+14 and +104°F).
Store between -20 and +55°C (-4 and 131°F).
Air humidity:
Lower than or equal to 50% at 40°C (104°F).
Lower than or equal to 90% at 20°C (68°F).
Altitude:
Up to 1000m above sea level (3,280 feet).
OPERATION
This remote control is designed to work with MIG / MAG , MMA and TIG welding processes. It can remotely operate the welding machine. The digi-
tal remote control can be switched on and off using the ON/OFF button. When the digital remote control is switched on, the welding machine/wire
feeder's interface switches off. A visual reprentation of the digital remote control appears on the welding machine/wirefeeder's interface. When the
digital remote control is switched off or disconnected, the welding machine/wirefeeder's interface switches back on.
EQUIPMENT DESCRIPTION (I)
1- Interface (MMI)
2- Remote control and power supply connector
3- ON/OFF button
CONNECTION (II)
The KIT NUM-1 option (063938) is required on the following products to connect the remote control:
NEOPULSE/PULSEMIG 400/500 G
NEOPULSE/PULSEMIG 320 C
NEOPULSE/PULSEMIG 400 CW
TITAN 231 DC FV
TITAN 321 DC TRI
TITANIUM 230 AC/DC
HUMAN-MACHINE INTERFACE (HMI)
Please read the user manual for the interface (HMI) supplied with your welding machine.
HMI
WARRANTY
The warranty covers faulty workmanship for 2 years from the date of purchase (parts and labour).
The warranty does not cover:
• Transit damage.
• Normal wear of parts (eg. : cables, clamps, etc..).
• Damages due to misuse (power supply error, dropping of equipment, disassembling).
• Environment related failures (pollution, rust, dust).
In case of failure, return the unit to your distributor together with:
- The proof of purchase (receipt etc ...)
- A description of the fault reported.
RC-HD2
4- USB connector
5- Remote control and power supply cable (option)
